IMT 3203i - Page 49

Parts 43 Section 4
3203i - Manual # 99904380
99904316-1
ITEM
NO.
PART
NO.
DESCRIPTION KIT NO. QTY.
1. 51721320 KIT-HRDW 3203 HYD BOOM ASY 1
3. 52721261 WLDMT- EXTENSION 1ST STAGE 3203I 1
4. 52724108 WLDMT-LOWER BOOM 3203I 1
5. 52725021 WLDMT- 2ND STAGE EXTENSION 3203I 1
7. 60030369 WEAR PAD-RND 0.19X 2.00X 0.60X .50 1
9. 60030374 WEAR PAD-RND 0.25X 1.00X .50X .31 6
10. 60030375 WEAR PAD-RND 0.30X 3.00X 1.00X .25 1
11. 60030376 WEAR PAD-RND 0.30X 3.50X 1.00X 0.615 2
12. 60132302 STOP SCREW 3/8-24 X .50 4
13. 60133938 WEAR PAD-RND 0.25X 1.00X .50X .50 STL 2
15. 71734311 PIN-QUICK RLSE .62D/4.5 CRIT 1
16. 71734314 PIN-QUICK RLSE .62D/5.75 CRIT 1
21. 72063051 WASHER .38 LOCK 1 4
23. 72661543 PIN-QUICK 316-10QP 2
24. 72661711 CLEVIS PIN .50 X 3.00 REF
25. 72661766 LOCKING PIN RUE RING .50 1
REV. S
