IMT 3203i Parts & Specifications

Parts 56 Section 4
3203i - Manual # 99904380
99904317 COMPLETE PARTS LIST
ITEM NO. PART NO. DESCRIPTION KIT NO. QT Y.
1. 99904315 DWG-BASE AND MAST ASM 3203 REF
2. 99904316 DWG-BOOM ASM 3203I REF
3. 51721321 KIT-HRDW 3203 CRANE & WINCH 1
4. 51724950 SNATCH BLOCK- 3203I-4004I 1
5. 52725018 WLDMT-ATB TRIP MECHANISM 1
6. 70580059 WIRE ROPE ASM-.22 X 7 X 19 X 65FT PGA 1
7. 71570922 WINCH-DC2000 12VDC 1
8. 77041932 CONTACTOR-WINCH 12V DC2000 1
9. 72034485 CLAMP-PLASTIC 1/4” CABLE 2
10. 77041459 SWITCH-LIMIT 1
11. 77441096 CONNECTOR- .50 STR RLF .25-.38 1
12. 77441278 GROUND STRAP- 8IN 1
13. 71413185 SPRING-.105WIRE 0.75OD 2.875 LG 3 1
14. 72060002 CAP SCR .25-20X .75 HH GR5 Z 3 4
15. 72060046 CAP SCR .38-16X 1.00 HH GR5 Z 3 2
16. 72060073 CAP SCR .44-14X 4.50 HH GR5 Z 3 1
17. 72062093 NUT # 8-32 HEX ZINC 3 1
18. 72062104 NUT .25-20 HEX NYLOCK 3 2
19. 72062105 NUT .44-14 HEX NYLOCK 3 1
20. 72062106 NUT 10-24 HEX NYLOCK 3 2
21. 72062207 NUT 8-32 HEX NYLOCK 3 3
22. 72063001 WASHER .25 FLAT 3 8
23. 72063002 WASHER .31 FLAT 3 2
24. 72063004 WASHER .44 FLAT 3 2
25. 72063049 WASHER .25 LOCK 3 6
26. 72063051 WASHER .38 LOCK 3 2
27. 72063271 WASHER # 8 W FLAT ANSI B27.2Z 3 6
28. 72601798 WASHER-LOCK 12MM 3 6
29. 72601935 CAP SCR M12-1.75X 40 SH ZC 3 4
30. 72601938 BOLT-EYE # 8/32X .75 3 1
31. 72601941 SCR-MACH .25-20X .38 BTNHD ZC 3 1
32. 77040051 TERM-SPRSPADE 1 #8 STUD 16-14 3 2
34. 72066535 CLAMP-LOOP .38 VINYL COVERED 1
35. 51727064
CORD REEL ASM - 4.17’ - W/PACKARD
CONNECTOR
1
36. 60144651 BRKT- CORD REEL MNT 1
37. 71415014 KEEPER-PIN .38 2
38. 60140618 PIN-TYPE NN 1.00 X 8.25 1
39. 60140617 PIN-TYPE NN 1.00 X 6.50 1
40. 72060209 CAP SCR .75-10X 2.75 HH GR8 Z 3 1
41. 72062114 NUT .75-10 HEX NYLOCK 3 1
42. 72063008 WASHER .75 FLAT 3 1
43. 60030483 SHEAVE- 8.0 NYLATRON GSM 1
44. 72601942 SCR-MACH # 6-32X 1.50 RND PHLPS 3 2
