Parts 63 Section 4
3203i - Manual # 99904380
51725007 PARTS LIST
ITEM NO. PART NO. DESCRIPTION
KIT
NO.
QTY.
1. 94397290 IMT SEAL KIT-1.50 BORE 1.00 ROD .75 STGR 1
2. 52722110 ROD ASM-1.00 DIA X 61.38 LG .75 S 1
3. 52725008 CASE ASM-1.50 BORE X 58.25 LG 1
4. 60135105 HEAD-1.50 BORE X 1.00 ROD (DUCTILE IRON) 1
5. 60132170 STINGER LOCK .75-16 X 1.75 LG 1
6. 60132173 STOP TUBE-1.00 ROD X 4.00 LONG 1
7. 60135106 PISTON-1.50 BORE X .75 STGR (DUCT IRON) 1
8. 73054999 VALVE-CBAL SUN01 CBBC-LHN 1
9. 76397127 WEAR RING-PISTON 1.50OD X .75W 1 1
10. 76397128 WEAR RING-ROD 1.00 ID X .38W 1 1
11. 76397129 ROD WIPER-TYPE AN 1.00 ROD 1 1
12. 76534502 U-CUP LOADED 1.00X1.25X.250 B 1 1
13. 76534503 U-CUP LOADED 1.25X1.50X.250 B 1 2
14. 7Q072018 O RING .75X .88X .06 70 1 1
15. 7Q072129 O RING 1.56X 1.75X .09 70 1 1
REV. INITIAL RELEASE
NOTES:
1. To reduce downtime, replace all components of the seal kit whenever the cylinder is disassembled.
2. Apply lubricating compound to threads on cylinder head only. Keep away from all seals.
3. Apply “lubriplate” no. 630-2 Medium heavy, multi-purpose lubricant, to all piston, head gland, and holding
valve seals, nylon lock ring, cast iron piston rings, and rod stinger threads.
