IMT 3203i Parts & Specifications

Parts 67 Section 4
3203i - Manual # 99904380
51721291 PARTS LIST
ITEM NO. PART NO. DESCRIPTION KIT NO. QTY
1 94397290 IMT SEAL KIT-1.50 BORE 1.00 ROD .75 STGR 1
2 52721292 ROD ASM-1.00 DIA X 61.38 LG .75 S 1
3 52721293 CASE ASM-1.50 BORE X 58.25 LG 1
4 60131651 HEAD-1.50 BORE X 1.00 ROD 1
5 60132170 STINGER LOCK .75-16 X 1.75 LG 1
6 60132173 STOP TUBE-1.00 ROD X 4.00 LONG 1
7 60132177 PISTON-1.50 BORE X .75 STGR 1
8 73054999 VALVE-CBAL SUN01 CBBC-LHN 1
9 76397127 WEAR RING-PISTON 1.50OD X .75W 1 1
10 76397128 WEAR RING-ROD 1.00 ID X .38W 1 1
11 76397129 ROD WIPER-TYPE AN 1.00 ROD 1 1
12 76534502 U-CUP LOADED 1.00X1.25X.250 B 1 1
13 76534503 U-CUP LOADED 1.25X1.50X.250 B 1 2
14 7Q072018 O RING .75X .88X .06 70 1 1
15 7Q072129 O RING 1.56X 1.75X .09 70 1 1
REV. INITIAL RELEASE

IMT 3203i Specifications

General

Brand	IMT
Model	3203i
Category	Construction Equipment
Language	English
