Parts 76 Section 4
3203i - Manual # 99904380
99904361 COMPLETE PARTS LIST
ITEM NO. PART NO. DESCRIPTION KIT NO. QTY.
1. 99904317 DWG-CRANE & WINCH ASM 3203I REF
2. 70145928 FLOW LIMITER-28051-806-1.0 6 1
3. 72532522 PLUG-STR HEX HD STL .44 2
4. 73540325 VALVE-PROP FLOW CNTRL 12V ELEC CRANE 1
5. 51725663 KIT-HYD 3203 REF
6. 51397335 HOSE-FZ .25 X 13.50 (4-4) 100R17 5 1
7. 51397336 HOSE-FI .25 X 12.50 (4-4) 100R17 5 1
8. 51397337 HOSE-FJ .25 X 7.00 (4-4) 100R17 5 1
9. 51397338 HOSE-FJ .25 X 9.25 (4-4) 100R17 5 1
10. 51397339 HOSE-FF .25 X 23.50 (4-4) 100R17 5 1
11. 72053758 ELBOW-M STR/90/M JIC 4 4 5 2
12. 72532351 ADPTR-M STR/M JIC 4 4 5 8
14. 72533567 ELBOW-M STR/90/M JIC XLG 4 4 5 1
15. 72533589 ADPTR-M STR/M JIC 10 4 5 2
16. 51395219 HOSE-FF .25 X 18.00 (4-4) 100R17 5 1
17. 51395872 HOSE-FF .25 X 21.00 (4-4) 100R17 5 1
18. 72531130 ELBOW-STREET STL .12 X 90 DEG 5 1
19. 51395380 HOSE-FF .25 X 22.00 (4-6) 100R17 5 1
20. 72532992 ADPTR-M STR/F STR 4 6 5 1
21. 91721626 KIT-HYD 3203 PROP REF
22. 51395663 HOSE-FJ .25 X 14.00 (4-4) 100R17 21 1
23. 51397339 HOSE-FF .25 X 23.50 (4-4) 100R17 21 1
24. 51397434 HOSE-FZ .25 X 16.00 (4-4) 100R17 21 1
25. 51397452 HOSE-FI .25 X 11.50 (4-4) 100R17 21 1
26. 72053758 ELBOW-M STR/90/M JIC 4 4 21 1
27. 72532351 ADPTR-M STR/M JIC 4 4 21 2
28. 72532981 TEE-SWVL NUT RUN JIC 4 21 1
29. 72534477 ADPTR-M STR/M JIC 4 4 XLG 21 1
30. 51721645 KIT-HRDW PROP CNTRL VALVE ELEC CRANE REF
31. 72060009 CAP SCR .25-20X 2.25 HH GR5 Z 30 2
32. 72063001 WASHER .25 FLAT 30 4
36. 72062104 NUT .25-20 HEX NYLOCK 30 2
34. 72534714 TEE-STL JIC/STR/JIC 4 6 4 BRANCH 5 1
35. 72532674 CAP-JIC STL 4 ( .44 THD) 5 1
37. 72534567 ELBOW-M STR/90/M JIC XLG 6 4 1
REV. R CN885-1
