99903514:TELESCOPIC CRANE: 5-7
SECTION 5: DECALS
Figure E-12
DECAL: Contact IMT
PART NUMBER: 70392982
FUNCTION: To provide the owners/operators and
maintenance personnel with the address and
telephone number of IMT for service and repair
purposes, safety questions, etc.
USED ON: All cranes.
PLACEMENT: Visible from the operator’s station.
QUANTITY: 1
Figure E-13
DECAL: Return Line
PART NUMBER: 70392109
FUNCTION: To aid in the identification of the
hydraulic system return line to minimize errors during
hydraulic maintenance.
USED ON: All cranes with hydraulic fluid reservoirs.
PLACEMENT: On the hydraulic fluid reservoir at the
return line.
QUANTITY: 1
Figure E-14
DECAL: Suction Line
PART NUMBER: 70392108
FUNCTION: To aid in the identification of the
hydraulic system suction line to minimize errors
during hydraulic maintenance.
USED ON: All cranes with hydraulic fluid reservoirs.
PLACEMENT: On the hydraulic fluid reservoir at the
suction line.
QUANTITY: 1
Figure E-15
DECAL: Lubricate Gear
PART NUMBER: 70392399
FUNCTION: To inform maintenance personnel of the
need to lubricate the rotation gear on a weekly basis.
USED ON: All cranes which use a gear drive for
crane swing.
PLACEMENT: On the gear cover.
QUANTITY: 1
SUCTION
LINE
70392108
RETURN
LINE
70392109
20050207
For service and repair
on this equipment, contact:
YOUR AUTHORIZED
DEALER
Visit our dealer locator:
www.imt.com
70392982
Weekly, remove cover and lubricate with
MOLUB-ALLOY 882 HEAVY
open-gear compound while rotating crane.
MOLUB-ALLO Y is a registered trademark of
Castrol Industrial PLD Downers Grove, I L 1-800-621-6221
70392399
