CHILD
WITH INBUILT HARNESS
Determine whether your child requires the additional padding provided with this restraint, to
ensure a safe and snug t in the restraint. Refer to page 6 for suggested padding combinations.
SELECTION OF APPROPRIATE PADDING COMBINATIONS
Refer to the shoulder height labels
(As shown on pages 21 and 22)
IMPORTANT
!
CONVERTING TO CHILD SEAT
Ensure the recline section is swung
rearward (see Figure 1).
At the front of the restraint is a red
lever. Pull red lever forward and slide
the seat to obtain the desired upright
or reclined angle.
FRONT
Recline
Upright
RED
LEVER
RECLINE
SECTION
Front
of Car
RECLINED POSITION
ADJUSTER ASSEMBLY LOCATION
PUSH
Pull excess strap through the top section
whilst feeding the adjuster section towards
the seat (see Figure 2).
Continue to shorten until you have reached the
desired position at the rear of the restraint (see
Figure 3).
Step 1:
Step 2:
Forward Facing (Type B)
Adjuster
1
1
2
2
Upper Anchorage Strap
Figure 2
Figure 1
Adjuster
position
Front
of Car
Figure 3
