InfiRay RL42 User Manual

⚫ Select ‘Zeroing Profile’ and press M button to enter
submenu;
⚫ Select one of Profile A/B/C via pressing↑button and ↓
button;
⚫ Press M button to confirm.
Reticle Type
Select Reticle type
⚫ Press M button to enter submenu of Reticle Type
⚫ Select “Reticle Type” then press M button to enter submenu;
⚫ Select one of seven reticle types via pressing ↑button and
↓button;
⚫ Reticle type changes while reticle moves.
⚫ Press M button to confirm.
Reticle Color
⚫ Press M button to enter submenu of Reticle Color
⚫ Select ‘Reticle Color’ then press M button to enter submenu
of reticle color;
⚫ Press↑button and ↓button to choose one of four

InfiRay RL42 Specifications

General

Sensor Resolution	384x288
Pixel Size	12 μm
Frame Rate	50 Hz
IP Rating	IP67
Type	Handheld
Battery	Lithium-ion
Battery Type	Lithium-ion
Operating Temperature	-20°C to +50°C
