InFocus IN116a User Manual

9
Adjusting the image
If necessary, adjust the height of the projector by rotating the elevator foot to
extend the foot.
If necessary, rotate the leveling foot located at the rear of the projector.
Avoid placing your hands near the hot exhaust vent at the front of the projector.
Position the projector the desired distance from the screen at a 90 degree angle to
the screen.
See page 6 for a table listing screen sizes and distances.
Adjust the zoom or focus.
If the image is not square, first make sure that the projector is perpendicular to the
s
creen. If the image is larger or smaller on the top or bottom edge of the screen,
press the top Keystone button
to reduce the upper part of the image, and
press the bottom Keystone button to reduce the lower part.
If the left or right side of the screen is larger or smaller the other, you can turn the
proj
ector to the left or to the right a few degrees to square the image.
Adjust the Contrast or Brightness in the Basic Menu. See page 25 for help with
these menu adjustments.
adjust distance
adjust zoom and focus
adjust keystone
Aspect Ratio
Auto Image
Brightness
Contrast
Auto Keystone
Keystone
Presets
Sharpness
Volume
Ceiling Mount
Advanced Menu
◄ Auto ►
Execute
50
50
Off
0
Presentation
16
16
Off
( Basic Menu )
MDL: IN112a
FW: 0.14
adjust Basic Menu
adjust height
elevator
foot

InFocus IN116a Specifications

General

White Brightness	3000 lumens
Native Resolution	1280 x 800
Contrast Ratio	15, 000:1
Aspect Ratio	16:10
Throw Ratio Range	1.5 to 1.8
3D	yes
Video Input	vga, hdmi, s-video, composite video
Inputs	hdmi, composite video, s-video, usb, vga
OS Compatibility	mac, windows

Weight and Dimensions

Depth	8.7 inches
Height	4.3 inches
Width	11.5 inches
Net Weight	5.4 pounds
