InFocus IN5124 - Communication Setup; Communication Port

74
6. Network Bridge Feature
6.2 Communication setup
6.3 Communication port
1) Using the COMMUNICATION TYPE menu, select NETWORK BRIDGE for
the CONTROL port.
2) Using the SERIAL SETTINGS menu, select the proper baud rate and
parity for the CONTROL port, according to the device's RS-232C port
specications.
For the NETWORK BRIDGE feature, send the data from the computer to the
projector When using the Network Bridge Port that is congured in the “Port
Settings” of web browser. (
&51)
3) Using the TRANSMISSION METHOD menu, select the appropriate
CONTROL port method based on your desired use.
• COMMUNICATION TYPE is defaulted to OFF.
• Using the COMMUNICATION menu, set up the communication. Remember
that an incorrect setup could result in a communication malfunction.
• When COMMUNICATION TYPE is set to NETWORK BRIDGE, the CONTROL
port does not accept RS-232C commands.
• Any number between 1024 and 65535 (except for 9715, 9716, 9719,
9720, 5900, 5500, and 4352) can be set up as the Network Bridge Port
number. 9717 is the default setting.
NOTE
NOTE
Item Condition
BAUD RATE 4800bps/9600bps/19200bps/38400bps
PARITY NONE/ODD/EVEN
Data length 8 bit (xed)
Start bit 1 bit (xed)
Stop bit 1 bit (xed)
To congure the projector for NETWORK BRIDGE communication, go
to the COMMUNICATION menu. Open the projector menu and select
COMMUNICATION. (&OPTION menu – SERVICE – COMMUNICATION in the
User’s Manual)
