13
3.2.9 MEASURES Menu Items
In this menu you can see all measured values. Use (↑) and (↓) keys for moving on submenu items.
Submenu item Function
1 LD%: 060 074 080
Output load percentage
2 OPV: 220 221 220
Output voltages
3 FREQU: 50.0 Hz
Output frequency
4 IPV: 240 235 220
Input voltages
5 BYP: 230 232 231
Bypass source voltages
6 IPI: 022 010 030
Input currents (amperes)
+BATT: 405 V 000 A
“+” Battery voltage and charge / discharge current
7
-BATT: 405 V 000 A
“-” Battery voltage and charge / discharge current
8 TEMP: 030 c
Cabinet inside temperature
9 BATT.CAPACI:068%
Battery charge level
10 ENTER <EXIT>
→ Enter (↵ ) exit from menu
Go to STATUS MENU
3.2.10 ALARMS Menu Items
In this menu you can see recorded log events and valid alarms
Submenu item Function
1 UPS STATUS
Alarm status at that instant
2 000>311201 23:15
Monitoring past alarms :
The first 3 digit number indicates the event number. 000 numbered event is
the last event. Date ddmmyy time:hh:mm
On the second line of LCD PANEL you can see al recorded alarms.
Use PLUS and MINUS keys for moving on events.
3 ENTER CLEAR LOG
→ Enter (↵ ) clear log event records
After you cleared events you see EMPTY LOG message.
4 PARR.ERR.NR : 017
Parallel control board fault number. (if the parallel board is installed)
0 means that there is no error on parallel board
5 ENTER <EXIT>
→ Enter (↵ ) exit from submenu
Go to STATUS MENU
3.2.11 INFORMATION Menu Items
This menu gives information about the UPS.
Submenu item Function
1 SYNC :OK COMM :OK
If the UPS is operating in syncron to mains SYNC:OK ,if not syncron SYNC:-
If communication is active COMM:OK ,if not active COMM:--
2 POWER: 120000 VA
The maximum power rating of the UPS
3 VERSION : B12
Shows the UPS control software version.
4 FREQUENCY : PLL
Frequency generation mode
PLL :phase locked loop is generating the frequency
SLAVE : in parallel system master is generating the frequency
5 NOM.FRQ: 50 Hertz
Nominal output frequency
6 MODEL: PDSP3120
Model name of the UPS
7 ENTER <EXIT>
→ Enter (↵ ) exit from submenu
Go to STATUS MENU
