3.2.12 ADJUST Menu Items:
Only service personnel can use this menu ,the incorrect use of this menu can cause damage to the UPS.
Submenu item Function
1 PASSWORD : XXX
Service password input
(-) key 100,
UP key 10,
(+) key 1 changes
after you write the password on screen press ENTER key ,if the password is
wrong the is no action.
If the password is okay a beep sounds and you see ADJUST MODE at the
second line.
2 ENTER <EXIT>
→ Enter (↵ ) exit from submenu
Go to STATUS MENU
3.2.13 OPTIONS Menu Items
In this menu the user can set some important parameters for UPS operation..
Submenu item Function
1 MODE: ONLINE
By using (+) and (-) keys you can move on 5 different operation modes.
ONLINE : stand alone mode
PARALLEL : 2 UPS in symmetric parallel operation
N+1 REDUNDANT : 2 or more UPS in N+1 redundant parallel mode
REDUNDANT: 2 UPS in redundant parallel mode.
ECONO: Off-line mode.
→ press ENTER for 3 seconds and the selection is valid
2 UPS No : 001
By using PLUS and MINUS keys you can change number 0 to 3.
In parallel operation select different number for each UPS. If you select the
same number DUBL UPS NUMBER message tells the fault.
→ press ENTER for 3 seconds and the selection is valid
3 REMOTE :ENABLE
By using PLUS and MINUS keys you can change enable and disable options.
Enable : remote battery test, shutdown and bypass functions are enabled
disable : these functions are disabled
→ press ENTER for 3 seconds and the selection is valid
4 RESTART:ON/OFF
By using PLUS and MINUS keys you can change on and off options.
ON: during mains failure, at the and of battery discharge UPS shutdowns, and
after mains is restored UPS starts again.
(battery trip out is on every time)
OFF: after mains restoration UPS doesn’t start by itself again. (You must turn
off and then turn on the UPS)
(battery trip out is off)
→ press ENTER for 3 seconds and then the selection is valid
5
RELAY:BATT.LOW
/COMMON
By using (+) key the function of the RL3 Relay on the interface board can be
selected between Battery Low or Common Alarm.
6
BATTERY
TEST:ON/OFF
By using PLUS and MINUS keys you can change on and off options. Used to
enable or disable automatic battery test.
7 ENTER <EXIT>
→ Enter (↵ ) exit from submenu
Go to STATUS MENU
To Next Page
