3.2.14 COMMAND Menu Items
This menu is used to give various commands, to the UPS or to perform some tests on it. .
Submenu items Function
1 SOUND : ON/OFF
Used for turning on/off the audible alarm.
If you press ENTER key the option will change (push ON, push OFF)
If the OFF option is selected, audible alarm is turned off but in case of a new
alarm, UPS changes the option to ON state.
2 ENTER B.TEST>405
If you press enter for 3 seconds battery test starts and lasts for 15 seconds. If
battery test fails A6 BATT FAULT message is shown on panel and this
message stays until you press ENTER key for 3 seconds.
The value on the right indicates the battery voltage during battery test.
Starting time of battery test is recorded to log event menu. If the test is
performed successfully you can see only BATTERY TEST message on log
records. If the test is unsuccessful a BATT.FAULT message will also be
recorded. On the bottom line of LCD, BAT FAULT message will stay, and the
user will be warned audibly every 15 seconds until this message is cleared
by pressing the ENTER key for 3 seconds.
3 ENTER <BYPASS>
If you press ENTER key for 3 the load is transferred to bypass.
If the load is on bypass, in this submenu you see ENTER<INVERTER>
message at this position. If you press ENTER key for 3 seconds UPS
transfers the load on inverter this time.
In parallel modes this function is disabled and you see BYP.FUNC.DISABLE
message on this submenu item.
4 ENTER:MODEM INIT
If you press ENTER key the connected modem of RS232 port is installed
UPS sends AT command set to modem for installation.
If the function is completed you must hear a beep sound.
At the and of this function modem is ready to answer dial up connection.
5 ENTER <BOOST>
If you press ENTER key for 3 seconds boost charge starts. The given time
for boost charge is 10 hours. At the end of this time UPS stops boost
charging.
If the boost charge is active this submenu item changes to STOP BOOST>
005H message. 005H indicating that boost charge has lasted for 5 hours.
If the number is 10, boost charge stops. If you press ENTER key before this
time boost charge stops immediately.
Boost charge starting and boost charge end times are recorded in log event
menu.
If boost is active UPS beeps every 15 seconds
6 SIMULATION OFF
The purpose of this submenu is to check dry contact connections. Normally
to check line failure contact you must turn off mains power. This is not
necessary with this utility. 3 options are available.
SIMULATION OFF simulation mode is off
SIM: LINE FAILURE if you press ENTER key for 3 seconds, the line failure
relay on the interface board is energized.
SIM: LIN.F+BT.LOW if you press enter key for 3 seconds line failure and
battery low relays are energized.
SIM: BYPASS if you press ENTER key for 3 seconds bypass relay is
energized.
This way, you can check dry contact connections
7 ENTER <EXIT>
→ Enter (↵ ) exit from submenu
Go to STATUS MENU
