INFOSEC UPS SYSTEM E4 Evolution II + TT Series User Manual

104
INFOSEC UPS SYSTEM – 15, rue du Moulin – 44880 Sautron – France – www.infosec-ups.com
hotline : +33 (0)2 40 76 15 82 – fax : +33(0)2 40 94 29 51 – hotline@infosec.fr – 07 19 AA 59 205 03
LV MODEL (208V)
E4
Evolution II +
10k TT
(S)
E4
Evolution II
+ 15k TT
(S)
E4
Evolution II
+ 20k TT
(S)
E4
Evolution
II + 30k TT
S
E4
Evolution II
+ 40k TT
S
CAPACITY*
10KVA
10KW
15KVA
15KW
20KVA
20KW
30KVA
30KW
40KVA
40KW
INPUT
Voltage
Range
Low Line Loss
70 VAC(Ph-N) ± 3 % at 50% Load
88 VAC(Ph-N) ± 3 % at 100% Load
Low Line Comeback
Low Line Loss Voltage + 5V
High Line Loss
156 VAC(L-N) ± 3 % at 50% Load
146 VAC(L-N) ± 3 % at 100% Load
High Line
Comeback
High Line Loss Voltage - 5V
Frequency Range
46Hz ~ 54 Hz @ 50Hz system
56Hz ~ 64 Hz @ 60Hz system
Phase
3 Phase with Neutral
Power Factor
≧ 0.99 at 100% Load
OUTPUT
Phase
3 Phase with Neutral
Output voltage
208/220VAC (Ph-Ph)
120/127VAC (Ph-N)
AC Voltage Regulation
± 1%
Frequency Range
(Synchronized Range)
46Hz ~ 54 Hz @ 50Hz system
56Hz ~ 64 Hz @ 60Hz system
Frequency Range (Batt. Mode)
50 Hz ± 0.1 Hz or 60Hz ± 0.1 Hz
Overload
AC mode
100%~110%: 60min; 110%~125%: 10min; 125%~150%:1min;>150% : immediately
Battery mode
100%~110%: 60min; 110%~125%: 10min; 125%~150%:1min;>150% : immediately
Current Crest Ratio
3:1 max
Harmonic Distortion
≦ 2 % @ 100% Linear Load; ≦ 4 % @ 100% Non-linear Load (PF≥0.8)
Transfer
Time
Line Battery
0 ms
Inverter
Bypass
0 ms (When phase lock fails, <4ms interruption occurs from inverter to bypass)
Inverter ECO
<10 ms
EFFICIENCY
AC mode
93.5%
Battery Mode
92.5%
BATTERY
Standard
Model
Type
12 V / 9 Ah
12 V / 7 Ah
12 V / 9 Ah
N/A
Numbers
(8+8)pcs
(8+8)pcs x 2 strings
Recharge Time
9 hours recover to 90% capacity
Charging
Current(max.)
1.0~12.0A±10% (Adjustable)
Charging Voltage
+/-109 VDC ± 1%
Long-run
Model
Type
Depending on applications
Numbers
16 ~ 20 (adjustable)
Charging
Current(max.)
1.0~12.0A±10% (Adjustable)
2.0~24.0A±10% (Adjustable)
Charging Voltage
+/- 13.65 VDC * N ± 1% (N = 8~10)
PHYSICAL
Standard
Model
Dimension,
D X W X H
mm
626 x 250 x 750
815 x 300 x
1000
815 x 300 x
1000
N/A
Net Weight (kgs)
139/141
152
117
Long-run
Model
Dimension,
D X W X H
mm
626 x 250 x 750
815 x 300 x
1000
815 x 300 x
1000
790 x 360 x
1010
790 x 360 x
1010
Net Weight (kgs)
43/45
60/65
61/71
108/112
113/117
ENVIRONMENT
Operation Temperature
0 ~ 40°C (the battery life will down when > 25°C)
Operation Humidity
<95 % and non-condensing
Operation Altitude**
<1000m**
