Connecting cables
WARNING
C
o
nn
e
c
t
i
n
g
i
s
t
o
b
e
m
a
de
wh
e
n
t
h
e
t
e
r
m
i
n
a
l
i
s
p
o
w
e
r
ed
o
ff
.
WARNHINWEIS
Die Anschlüsse müssen bei ausgeschaltetem Terminal
erfolgen.
Perform the following operations:
Open down side
trapdoor then unclips
the cables hook
Plug telephone line , equipped
if
necessary with user
country specific converter , to the telephone network (*).
Connect the other end to the terminal telephone connection .
If
necessary, connect the telephone (Telephone
is
not required
for the terminal to operate)
Optionally plug others cables (Ethernet, RS232, USB…)
Plug PSU power lead into the power socket .
To Next Page
