Nets One PA user guide | 12
Nets Spire terminal range
SPc5 – Terminal overview
Four status LEDs
Colour display
Displays merchant menu
system and transaction
progress
Power button
Press button to turn the
terminal on
USB port
For connecting peripheral
equipment
Chip card reader
Use when the cardholder presents a chip
card
Keypad
For merchants & cardholder data entry
SIM/SAM compartment
Please do not open unless instructed
Serrated paper cutter
Receipts will emerge from
this slot and can be removed
by pulling across the ser-
rated cutter
Paper roll compartment
Power supply socket
This is where the power
supply plugs into the termi-
nal
Terminal connections
This is where the PIN Pad,
telephone line, network
and serial cables attach
Cable tidy
A removable clamp keeps
cables in place & prevents
disconnection
Swipe card reader
Use when the cardholder
presents a debit or credit
card without a Chip or
when prompted by the ter-
minal
