0.3 DECALS
This section contains representative examples of decals
which will be appearing throughout this manual and are
applied to the compressor unit. If for some reason a
decal is defaced, painted over, or parts are replaced, we
recommend that you obtain a replacement kit as listed in
the spare parts section of the Parts List Manual (Form
APDD 751).
Air discharge.
NOTICE
INGERSOLLrAND®
DANGER
!
Discharge air.
Can contain carbon monoxide or
other contaminants. Will cause
severe injury or death.
Do not breathe this air.
INGERSOLLrAND ®
Lift here.
NOTICE
INGERSOLLrAND®
Condensate drain.
NOTICE
INGERSOLLrAND®
39557095
(50-100 HP)
39540257
39540166
39540273
(4) 2 EACH END
39541081
54425996
(37-75 KW)
NOTICE
NOTICE
NOTICE
To obtain satisfactory compressor
operation and maintenance, a
minimum of 3 feet clearance on 3
sides is required. 3 1/2 feet is required
in front of the control panel (or
minimum required by latest national
Electrical Code or applicable local
codes).
Refer to the Operators/Instruction
Manual before performing any
maintenance.
Do not operate without enclosure
panels & forklift covers in place.
Enclosure panels will affect
performance.
Motors must be greased periodically.
See Operators Manual for procedure.
