InHand Edge Computer EC300 Series - Page 13

3
AIN1-
4
GND
Extension
Module B
5
B_232_TX/485_A/CAN2_H/AIN2+
6
B_232_RX/485_B/CAN2_L
7
AIN2-
8
GND
Extension
Module C
9
CAN3_H
10
CAN3_L
11
DO0
12
DO1
13
DO2
14
DO3
15
DI0
16
DI1
17
DI2
18
DI3
