The following table shows the maximum number of devices supported by the various control
panel models.
Table 2-2: Type SD and distribution of currents
Prime control panel models Prime060S Prime060L Prime120L Prime240L Prime500L
SD type
(backup battery)
rated voltage 12V
maximum capacity 7Ah 9Ah 17Ah 18Ah 17Ah 18Ah 17Ah 18Ah 17Ah 18Ah
maximum recharge time 24h (80% charged)
maximum internal resistor (R
i max
)
1.50Ohm 0.50Ohm
Maximum deliv-
erable current @
12V
total 3.7A 6.2A
for external loads
autonomy 30h
(
a
)
50mA 120mA 380mA 420mA 380mA 420mA 380mA 420mA 380mA 420mA
autonomy 12h
(
b
)
400mA 570mA 1230mA 1320mA 1230mA 1320mA 1230mA 1320mA 1230mA 1320mA
autonomy 4h (
c
)
1570mA 2070mA 4070mA 4320mA 4070mA 4320mA 4070mA 4320mA 4070mA 4320mA
Max. current available on each +AUX terminal 1500mA
Maximum deliverable current to open-
collector outputs
T1, .., T10 250mA
OC1, OC2 500mA
a. The system autonomy in absence of the primary power source can be limited to 30h for systems with security grade 3 or 4, that is,
as long as the primary power source failure is notified to an alarm receiving centre or to another remote control panel.
b. If the system is declassified to grade 2, autonomy can be limited to 12h.
c. For type A or B power supplies, if the system includes an ancillary power supply that switches automatically between the primary
power source and the ancillary power-supply, the autonomy can be limited to 4h regardless of the system security grade.
Table 2-3: Control panel - main features
Prime control panel models Prime060S Prime060L Prime120L Prime240L Prime500L
Partitions 10 20 30
Total zones 120 240 480 1000
Keypads 10 15 30
Voice memo slots 10
Expansions 100
Readers 20 30 60
Sounders/flashers 10
Wireless transceiver 20 30
Electronic keys and wireless remote controls 150 500
Possible key combinations 4294967296
Isolators 16
GSM, GPRS, UMTS, HSPA and LTE communicator 1
Temperature probes 15
Home-automation modules 30
Wi-Fi boards 1
Codes 50 100 500
Scenarios 30 50
Timers 20 40
Recordable events 4000
Programmable events 30 50 60
Table 2-4: Number of terminals
Prime control panel models Prime060S Prime060L Prime120L Prime240L Prime500L
Termina l s on
panel
total 10
configurable as inputs 10
configurable as roller shutter/shock 10
configurable as outputs 10
Wireless terminals 60 120 195 195
terminals on keypads 20 30 60
