Control panel and peripherals 9
Chapter 2 Control panel and peripherals
2-1
Prime control panels
2-1-1
Package contents
Inside the package you will find:
• Metal enclosure containing the motherboard and wired power supply
• User's Manual
• Quick guide to installation and programming
• Plastic bag containing:
- 20 x 3k9 Ohm 1/4W resistors
- 20 x 6k8 Ohm 1/4W resistors
- Connection wire for the backup battery
- Eyelet terminal for the connection to earth
- Nut for the eyelet terminal
- Thermal probe for optimization of the battery charging process
- 2 screws to secure the front plate of the metal enclosure
- screw with 6mm wall plug for the anti-dislodgement device
- Sticker: “Area protected by INIM Electronics security system”
The control panel data labels are affixed to the outside of the control panel enclosures.
2-1-2
Control panel descriptions
Area
protected
by security
system
Table 2-1: Control panels - electrical and mechanical features
Prime control panel models Prime060S Prime060L Prime120L Prime240L Prime500L
Voltage
Power supply 230V ~ -15% +10% 50/60Hz
nominal output 13.8V
output range from 9 to 13.8V
Current absorption
maximum 0.5A 1.1A
of the control panel mother-
board
180mA @ 13.8V
Fault voltage on power outputs 9.8V
Protection tripping volt-
age
from deep discharge 9.5V
from overload 15.4V
Maximum power-supply voltage ripple 550mV 200mV
PS type A
Maximum voltage on I-BUS 4A
Type of alarm notification (EN 50131-1, par. 8.6)
D (
a
)
IP Protection grade 30
Enclosure Dimensions (W x H x D) 27.5 x 37.4 x 8.6 cm 37.5 x 46.6 x 9.2 cm
Weight (without battery) 3.2Kg 5Kg
Security grade
EN50131-3 3
EN50131-6 3
a. Also notification types A, B and C are possible depending on the configuration of the control panel and system.
