User’s Manual
INNO Instrument, Inc.
26
PAGE
①
Select [Heater Mode] menu.
②
Select [Delete Heat Mode].
③
Select the heat mode to be
deleted
Heat Mode Parameters
③ Select the parameters to be
edited.
Delete Heat Mode
Parameter Description
Template
Set sleeve type. List of all heat modes are displayed.
Selected mode will be copied to a user-programmable area.
Name Title for a heat mode.
Note
Title of the heat mode displayed in the upper right corner of
the monitor during splicing or heating process. Max number
of characters used is 5.
Heater temperature Sets heating temperature.
Heater time
Sets heating time from the beginning to the heating
completed.
Preheat
temperature
Sets preheat temperature of the heater.
Note:
The gray modes (20mm, 30mm) are the system preset
initial heat modes which cannot be deleted
To Next Page
