INNO Instrument View 8+ - Error Message Troubleshooting Part 3; Fiber Contamination Errors; Splice Point Quality Errors

User’s Manual
INNO Instrument, Inc.
41
PAGE
Error Message Cause Solution
Fiber is Dirty
There’s dust or dirt
on the fiber surface
Prepare the fiber (stripping,
cleaning, and cleaving) again.
Dust or dirt is on the
lens or LEDs
Execute the “Dust Check”. If dust
or dirt exists, clean the lenses or LEDs
“Cleaning Arc
time” is too short
Set the “Cleaning Arc time” to
180ms
Splice the fibers
whose cores are
difficult to find by
the way of core
alignment.
Splice the fibers whose cores are
difficult to find by MM splice mode
(cladding layer alignment).
Fat Splicing Point
Too much [Overlap]
setting
Adjust or initialize “Overlap” setting.
The motor is not
calibrated.
Calibrate the arc power with the “Arc
Calibration” function.
Thin Splicing Point
Inadequate arc
power
Calibrate the arc power with the “Arc
Calibration” function.
Pre-fuse power or
time is set too high
Adjust or initialize “Pre-fuse Power”
or “Pre-fuse Time” settings.
Insufficient
“Overlap” setting
Adjust or initialize
“Overlap” setting
