 DO Setting
Function
Code
Parameter Name
Setting Range
Unit
Default
Commission
F5-02
Relay function
(T/A-T/B-T/C)
0: No output
1: AC drive running state
2: Fault output
3: Frequency-level detection FDT1 output
4: Frequency reached
5: Zero-speed running (no output at stop)
6: Motor overload pre-warning
7: AC drive overload pre-warning
8: Set count value reached
9: Designated count value reached
10: Length reached
11: PLC cycle complete
12: Accumulative running time reached
13: Frequency limited
14: Reserved
15: Ready for RUN
16: Reserved
17: Frequency upper limit reached
18: Frequency lower limit reached
(no output at stop)
19: Undervoltage state output
20: Communication setting
21: Reserved
22: Reserved
23: Zero-speed running 2
(having output at stop)
24: Accumulative power-on time reached
25: Frequency level detection FDT2 output
26: Frequency 1 reached
27: Frequency 2 reached
28: Current 1 reached
29: Current 2 reached
30: Timing reached
31: AI1 input limit exceeded
32: Load lost
33: Reverse running
34: Zero current state
35: Module temperature reached
36:Software current limit exceeded
37: Frequency lower limit reached
(having output at stop)
38: Alarm output
39: Reserved
40: Running time reached this time
41: Fault output (There is no output if it is the
coast to stop fault and undervoltage
occurs.)
N.A.
2
Fault output
F5-18
Relay 1 output delay
time
0.0 to 3600.0
s
0.0
