System components
Product Support: www.instron.com
Ground connection detail
If the electrical supply is not grounded, you must use this functional ground connection
to connect the frame to a suitable ground in the building.
This connection can also be used in certain cases when auxiliary equipment, such as an
automatic extensometer or a monitoring device, requires grounding for functional
reasons or for EMC compliance. Any instructions for connection to this ground will be in
the documentation for the accessory.
Refer to Figure 10 on page 42 for connection details.
2 Foot switch connector
3Status indicators
4 PIP jack
5 Strain connectors Optional
6Status indicators
7 Force connector Connects to load cell
8 Sync connector
9 Service connectors For use by Instron
®
Service
only
Label Component More detail
