Default System Configuration Parameters
Parameter
Value
Description
Run log file
Base
File that records PID settings
and error for the loading
history
Auto saving
Disabled
Allows data to automatically
be saved to a USB thumb
drive
Graph
Acquisition
40 Hz
Data acquisition rate (1, 2, 5,
10, 20, 40 Hz)
Encoder
speed
Enabled
If Enabled, the test is
performed using the
displacement rate
determined by the encoder
for the ram. If Disabled, the
displacement rate is
determined using the LVDT.
P-I-D
Constants
2.5-4.0-0.08
Control parameters for
displacement control
Manual
speed
50.0
Displacement speed for
moving to Home and Test
positions as well as the default
speed for the manual mode
Touch
speed
5
Displacement speed for
creating contact with the
specimen
Position
Return
Disabled
Moves the ram down to
release the load when the test
is finished.
