18. Channel Configuration & Calibration
Follow the instructions below to verify and calibrate the
measurement sensors, such as LVDT and load cell.
1. Press on the main menu to enter system
configuration.
2. Select the appropriate profile.
a. Press to change the profile. (Password –
1111).
b. Select Profile 1 for 10 kN and Profile 2 for 50 kN
load cells.
c. Exit the profile menu.
3. If calibrating a load cell, change the manual rate to
0.01 mm/minute in the Device Configuration menu (see
Section 17).
4. Then, press to enter the channel configuration
menu. (Password - 3333).
5. Select the appropriate channel.
a. Channel 1 is the calibration of the load cell.
b. Channel 2 is the calibration for the LVDT.
