 4. Digital Audio Input
Change input assignment between the input selectors and DIGITAL IN COAXIAL/
OPTICAL jacks. If you do not assign a jack, select "---".
Setting Item Default Value Setting Details
BD/DVD COAXIAL "COAXIAL", "OPTICAL": Assign a desired DIGITAL
IN jack to the BD/DVD button.
GAME --- "COAXIAL", "OPTICAL": Assign a desired DIGITAL
IN jack to the Game button.
CBL/SAT --- "COAXIAL", "OPTICAL": Assign a desired DIGITAL
IN jack to the CBL/SAT button.
STRM BOX --- "COAXIAL", "OPTICAL": Assign a desired DIGITAL
IN jack to the STRM Box button.
PC --- "COAXIAL", "OPTICAL": Assign a desired DIGITAL
IN jack to the PC button.
CD --- "COAXIAL", "OPTICAL": Assign a desired DIGITAL
IN jack to the CD button.
TV OPTICAL "COAXIAL", "OPTICAL": Assign a desired DIGITAL
IN jack to the TV button.
PHONO --- "COAXIAL", "OPTICAL": Assign a desired DIGITAL
IN jack to the PHONO button.
• Supported sampling rates for PCM signals (stereo, mono) from a digital input are 32 kHz,
44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz/16 bit, 20 bit, and 24 bit.
 5. Analog Audio Input
Change input assignment between the input selectors and AUDIO IN jacks. If you
do not assign a jack, select "---".
Setting Item Default Value Setting Details
BD/DVD AUDIO 1 "AUDIO 1" to "AUDIO 4": Assign a desired AUDIO
IN jack to the BD/DVD button.
GAME --- "AUDIO 1" to "AUDIO 4": Assign a desired AUDIO
IN jack to the Game button.
CBL/SAT AUDIO 2 "AUDIO 1" to "AUDIO 4": Assign a desired AUDIO
IN jack to the CBL/SAT button.
STRM BOX AUDIO 3 "AUDIO 1" to "AUDIO 4": Assign a desired AUDIO
IN jack to the STRM Box button.
PC --- "AUDIO 1" to "AUDIO 4": Assign a desired AUDIO
IN jack to the PC button.
CD AUDIO 4 "AUDIO 1" to "AUDIO 4": Assign a desired AUDIO
IN jack to the CD button.
TV --- "AUDIO 1" to "AUDIO 4": Assign a desired AUDIO
IN jack to the TV button.
PHONO PHONO The setting cannot be changed.
