4. Source
1. IntelliVolume
Adjust the volume level when there are dierences in volume level among multiple
devices connected to this unit. Select the input selector to make the setting.
Setting Item Default Value Setting Details
IntelliVolume 0 dB Select a value between "-12 dB" and "+12 dB".
Set a negative value if the volume of the target
device is larger than the others and a positive
value if smaller. To check the audio, play back the
connected device.
• This function does not work in Zone 2.
2. Name Edit
Set an easy name for each input. The set name appears on the main unit’s
display. Select the input selector to make the setting.
Setting Item Default Value Setting Details
Name Edit Input name 1. Select a character or symbol with the cursors,
and press Enter.
Repeat this operation to input up to 10 characters.
"A/a": Switches between upper and lower cases.
(Pressing Mode on the remote controller also
toggles between upper and lower cases)
"←" "→": Moves the cursor in the arrow direction.
"
": Removes a character on the left of the
cursor.
" ": Enters a space.
• Pressing Clear on the remote controller will
remove all the input characters.
2. After inputting, select "OK" with the cursors, and
press Enter.
The input name will be saved.
To restore the name to the default value, press
Clear on the remote controller on the input screen.
Then while nothing is entered, select "OK", and
press Enter.
• To name a preset radio station, press Tuner on the remote controller, select AM/FM, and
select the preset number.
• This cannot be set if the "NET" or "BLUETOOTH" input is selected.
Audio Select
Select the priority for input selection when multiple audio sources are connected
to one input selector, for example, connections to both the "BD/DVD" HDMI IN
jack and the "BD/DVD" AUDIO IN jack. The setting can be made for each input
selector button. Select the input selector to make the setting. Note that some of
the default values cannot be changed.
Setting Item Default Value Setting Details
Audio Select BD/DVD:
HDMI
GAME:
HDMI
CBL/SAT:
HDMI
STRM BOX:
HDMI
PC:
HDMI
AUX:
Analog
CD:
OPTICAL
PHONO:
Analog
TV:
OPTICAL
"ARC": When giving priority to the input signal from
ARC-compatible TV.
• This item can be selected only when "6.
Hardware" - "HDMI" - "Audio Return Channel" is
set to "Auto" and also the "TV" input is selected.
"HDMI": When giving priority to the input signal
from HDMI IN jacks
• This item can be selected only when the input
to be set is assigned to the HDMI jack in the "1.
Input/Output Assign" - "HDMI Input" setting.
"COAXIAL": When giving priority to the input signal
from DIGITAL IN COAXIAL jacks
• This item can be selected only when the input
to be set is assigned to the COAXIAL jack in the
"1. Input/Output Assign" - "Digital Audio Input"
setting.
"OPTICAL": When giving priority to the input signal
from DIGITAL IN OPTICAL jacks
• This item can be selected only when the input
to be set is assigned to the OPTICAL jack in the
"1. Input/Output Assign" - "Digital Audio Input"
setting.
"Analog": When giving priority to the input signal
from AUDIO IN jacks
• This item can be selected only when the input
to be set is assigned to the AUDIO IN jack in the
"1. Input/Output Assign" - "Analog Audio Input"
setting.
