1. DIGITAL IN OPTICAL/COAXIAL jacks: Input TV or AV component digital audio
signals with a digital optical cable or digital coaxial cable.
2. TUNER AM/FM terminal: Connect the supplied antennas.
3. VIDEO IN jacks: Input AV component video signals with an analog video cable.
4. Wireless antenna: Used for Wi-Fi connection or when using a BLUETOOTH-
enabled device. Adjust the angles according to the connection status.
5. USB port: Connect a USB storage device to play music les. ( p56) You
can also supply power (5 V/1 A) to USB devices with a USB cable.
6. ETHERNET port: Connect to the network with a LAN cable.
7. COMPONENT VIDEO IN jacks: Input AV component video signals with a
component video cable. (Compatible only with 480i or 576i resolution.)
8. HDMI OUT jacks: Transmit video signals and audio signals with an HDMI
cable connected to a monitor such as a TV or projector.
9. HDMI IN jacks: Transmit video signals and audio signals with an HDMI cable
connected to an AV component.
10.
RS-232C port: Connect a home control system equipped with an RS-232C
port. For adopting a home control system, contact the specialized stores.
11.
AC INLET: Connect the supplied power cord.
12.
GND terminal: Connect the ground wire of the turntable.
13.
AUDIO IN jacks: Input TV or AV component audio signals with an analog audio
cable.
14.
SPEAKERS terminals: Connect speakers with speaker cables. (North
American models are compatible with banana plugs. Use a plug 4 mm in
diameter. Y plug connection is not supported.)
15.
ZONE B LINE OUT jacks: Connect to a pre-main amplier with an analog
audio cable, and simultaneously output audio of the same source as that of
the speakers (ZONE A) connected to this unit.
16.
SUBWOOFER PRE OUT jacks: Connect a powered subwoofer with a
subwoofer cable. Up to two powered subwoofers can be connected. The same
signal is output from each SUBWOOFER PRE OUT jack.
17.
IR IN A/B, IR OUT jacks: Connect a remote control receiver unit.( p44)
18.
12V TRIGGER OUT A/B/C jack: Connect a device equipped with a 12V trigger
input jack to enable power link operation between the device and this unit.
( p45)
