> Before start > Hookup > Setup > Playback > Part Names
Step3: Connect the TV
TV
1
HDMI IN (ARC)
1 HDMI cable
if you have:
ARC TV
This unit is connected between your TV and AV
components. If you connect two or more AV components,
you can select the video displayed on the TV and the
audio output from this unit by changing the input selector.
Shown here are the connections for a TV that supports
the ARC (Audio Return Channel) feature. By connecting
with a single HDMI cable, you can not only output the
video input to this unit to the TV, but you can also play the
sound from the TV through this unit.
Choose an HDMI IN jack on the TV that supports ARC
when connecting.
Setup
0 Settings are required to use the ARC function.
Select "Yes" in "5. Audio Return Channel" (
Ä
P19)
in the Initial Setup.
0 Please refer to the TV's operation manual for
directions on connections and setup for the TV.
