15
> Before start > Hookup > Setup > Playback > Part Names
OR
CD
2
1
1 Digital optical cable, 2 Analog audio cable
if you have:
Audio Components
Example of a connection with an audio component.
Connect a CD player using a digital optical cable or
analog audio cable. You can also connect a turntable that
has an MM-type cartridge to the PHONO jack.
0 If the turntable has a built-in audio equalizer, connect it
to an AUDIO IN jack other than the PHONO jack.
Further, if the turntable uses an MC type cartridge,
install an audio equalizer compatible with the MC type
cartridge between the unit and the turntable, then
connect to any AUDIO IN jack other than the PHONO
jack.
If the turntable has a ground wire, connect it to the GND terminal
of this unit.
SN29402195_DRX-2_BAS_En_1602xx.book 15 ページ ２０１６年２月２２日 月曜日 午前１０時４分
