Integra DRX-7.1 User Manual

29
> Specifications > Advanced Setup > Listening Modes
> Network Functions > Basic Manual
|Troubleshooting Supplementary Information, etc.
Setting Item Default Value Setting Details
NET Main
Set the 12V trigger output setting to each input.
"Off": No output
"Main": Output when "
NET
" is selected as input for
main room.
"Zone 2": Output when "
NET
" is selected as input
for ZONE2.
"Main/Zone 2": Output when "
NET
" is selected as
input for main room or ZONE2
.
"
Zone 3
"
: Output when
"NET"
is selected as
input
for ZONE3.
"
Main/Zone 3
"
: Output when
"NET"
is selected as
input for main room or ZONE3.
"
Zone 2/Zone 3
"
: Output when
"NET"
is selected as
input for ZONE2 or ZONE3.
"
Main/Zone 2/Zone 3
"
: Output when
"NET"
is
selected as input for main room, ZONE2 or
ZONE3.
■ 5. 12V Trigger B
Set when outputting the control signal (maximum 12 V/25 mA) through the 12V TRIGGER
OUT B jack. Different settings can be set for each input selector. You can enable power link
operation when you connect the unit and the external devices equipped with 12V trigger
input jack.
Setting Item Default Value Setting Details
Delay 1 sec Set after how many seconds the 12V trigger output
will occur in response to the unit's operation. As
some devices cause a large current when they turn
on, delay the output if such devices are connected.
Select a value between "0 sec" to "3 sec".
Setting Item Default Value Setting Details
BD/DVD Zone 2
Set the 12V trigger output setting to each input.
"Off": No output
"Main": Output when "BD/DVD" is selected as
input
for main room.
"Zone 2": Output when "BD/DVD" is selected as
input
for ZONE2.
"Main/Zone 2": Output when "BD/DVD" is selected
as input for main room or ZONE2.
"
Zone 3
"
: Output when
"
BD/DVD
"
is selected as
input
for ZONE3.
"
Main/Zone 3
"
: Output when
"
BD/DVD
"
is selected
as input for main room or ZONE3.
"
Zone 2/Zone 3
"
: Output when
"
BD/DVD
"
is
selected as input for ZONE2 or ZONE3.
"
Main/Zone 2/Zone 3
"
: Output when
"
BD/DVD
"
is selected as input for main room, ZONE2 or
ZONE3.
CBL/SAT Zone 2
Set the 12V trigger output setting to each input.
"Off": No output
"Main": Output when "
CBL/SAT
" is selected as
input for
main room.
"Zone 2": Output when "
CBL/SAT
" is selected as
input for ZONE2.
"Main/Zone 2": Output when "
CBL/SAT
" is selected
as input for main room or ZONE2
.
"
Zone 3
"
: Output when
"CBL/SAT"
is selected as
input
for ZONE3.
"
Main/Zone 3
"
: Output when
"CBL/SAT"
is selected
as input for main room or ZONE3.
"
Zone 2/Zone 3
"
: Output when
"CBL/SAT"
is
selected as input for ZONE2 or ZONE3.
"
Main/Zone 2/Zone 3
"
: Output when
"CBL/SAT"
is selected as input for main room, ZONE2 or
ZONE3.
