Integra DTR-10.5 Brochure & Specs

A truly great home theater receiver will sport a design
and features that set it apart from the rest. The DTR-10.5
earns its place at the top with a unique modular design
which features a vast array of the latest digital
and analog inputs and outputs.
I
NCLUDED MODULES
A Unique Modular Design Sets
The New Benchmark in Audio Engineering
E
REMOTE
CONTROL
MAIN
ZONE 3
ZONE 2
IN
AC INLET
A
L
R
FRONT SURR SURR
BACK
CENTER
SUB
WOOFER
SUB
WOOFER
FRONT L CENTERFRONT R SURR BACK L
(
ASSIGNABLE
)
SURR R SURR L
FRONT
R
(
BTL
)
FRONT L
(
BTL
)
IR
12V
TRIGGER
OUT
RS 232
PRE OUT A
(
SINGLE
)
PRE
OUT B
C
E
200mA MAX.
100mA MAX.
100mA MAX.
100
mA MAX.
100mA MAX.
AC 120V 60Hz
SWITCHED
120W 1A MAX.
AC OUTLET
UDC/ UDT
SPEAKERS A
SPEAKERS B
22
1
66
55
44
33
22
11
OPTICAL COAXIAL
AUDIO IN
1
3
2
1
PH
2
3
9
8
7
6
5
4
4
5
RL
LR
L
R
R L
G
IN 1
IN 2
HDMI, the HDMI logo
is a trademark
or registered
trademarks of HDMI
Licensing LLC.
HDMI
S VIDEO VIDEO
IN IN
IN
1
IN 2
3
2
1
Y
P
B
P R
COMPONENT
VIDEO
IN 3
6
5
4
Y
P
B
P R
2
1
4
3
Y
P
B
P R
Y
P
B
P R
COMPONENT VIDEO
IN 4
ANTENNA
FM
75
B
SURR BACK R
(
ASSIGNABLE
)
A
B
D
DIGITAL IN DIGITAL IN
L
R
S VIDEOS VIDEO VIDEOVIDEO
OUT
CD F
G
HI JK L
MODEL NO. DTR-10.5
CD
OUT
OUT
F
L
OUT
IH
OUT OUT
J
K
AB
OUT 1
OUT 2
AM
GND
1
“Net
-
Tune”
is a trademark of
Onkyo Corporation.
ETHERNET
(
Net
-
Tune
)
A UDIO
The i.LINK logo is a
trademarks of Sony
Corporation, registered
in the U.S. and other
countries.
S400
SBR SBL
SR SL
SUB C
FR
FL
SBR SBL
SR SL
SUB C
FR
FL
MULTI
-
CH
IN 1
MULTI
-
CH
IN 2
A B C D E F G H I J K L
Module
Digital Audio
C-DGTL
Features six optical and
coaxial inputs, and two
optical and coaxial outputs.
Dual Texas Instruments
®
DSPs handle signal
processing. Superb DACs
from Wolfson Electronics
feature signal-to-noise
ratios much better than
typically found in an
integrated receiver.
DC
Module
Video
C-VIDEO
Features six composite
and S-video inputs plus
four assignable outputs.
Component video switching
includes three HD compatible
inputs and one output. All
composite and S-video inputs
are upconverted to 480i
component.
IH
Module
Analog Audio
C-ANLG
Features nine two-channel
analog inputs for conventional
sources, as well as a dedicated
phono input. Five outputs
are configurable for
Main/Zone2/Zone3, both
fixed and variable outputs
are supported.
GF
Module
AM/F
M T
uner
C-AM
F
M
F
eatures 4
0 AM/FM presets.
Discrete tuning and preset
station recall are supported
via IR and RS-232.
K

Integra DTR-10.5 Specifications

Amplifier Specifications

amplifier power output at 6 ohms	200 W per channel
amplifier power output at 8 ohms	150 W per channel
dynamic power output at 3 ohms	2 x 340 W
dynamic power output at 4 ohms	2 x 260 W
dynamic power output at 8 ohms	2 x 175 W
frequency response	5 Hz to 100 kHz
signal-to-noise ratio	110 dB
total harmonic distortion	0.08%
damping factor	60 at 8 ohms

Input and Output Specifications

line input sensitivity and impedance	200 mV, 50 k ohms
multi-channel input sensitivity and impedance	200 mV, 50 k ohms
subwoofer input sensitivity and impedance	36 mV, 50 k ohms
rec out level and impedance	200 mV, 470 ohms
pre out level and impedance	1 V, 470 ohms
zone 2/3 line output level and impedance	100 mV, 470 ohms

Radio Specifications

AM tuning range	530–1, 710 kHz
AM usable sensitivity	30 µV
FM tuning range	87.5–108.0 MHz
FM usable sensitivity, stereo	17.2 dBf, 2.0 µV (75 ohms IHF)

Phono and Tone Control

phono input sensitivity	2.5 mV, 50 k ohms
phono overload	70 mV RMS at 1 kHz, 0.5% THD
RIAA deviation	20 Hz to 20 kHz: ±0.8 dB
phono signal-to-noise ratio	80 dB
bass control	±12 dB at 50 Hz
mid range control	±12 dB at 1, 000 Hz
treble control	±12 dB at 20, 000 Hz

General Specifications

power supply	AC 120 V, 60 Hz
power consumption	13.0 A
dimensions	435 x 175 x 429 mm
weight	32.1 kg
