Getting to Know the AV Receiver
—Continued
P
TAPE IN/OUT
This analog audio input and output are for connect-
ing a recorder with an analog audio input and out-
put, such as a cassette deck, MD recorder, etc.
Q
VIDEO 3 IN
A VCR for playback only, or a cable or satellite
receiver can be connected here. There’s S-Video and
composite video input jacks for connecting the
video signal.
R
VIDEO 1 IN/OUT and VIDEO 2 IN/OUT
One or two video components can be connected
here for recording and playback, such as a VCR.
There’s S-Video and composite video input and out-
put jacks for connecting the video signal.
S
DVD IN
This input are for connecting a DVD player. There’s
S-Video and composite video input jacks for con-
necting the video signal, and stereo (FRONT) and
multichannel 5.1 jacks for connecting the analog
audio signals.
T
ZONE 2 SPEAKERS
These terminal posts are for connecting speakers in
Zone 2.
U
PRE OUT SUBWOOFER
This jack is for connecting a powered subwoofer.
V
FRONT, CENTER, and SURROUND
SPEAKERS
These terminal posts are for connecting the front
L/R, center, and surround L/R speakers.
W
AC OUTLETS
These switched AC outlets can be used to supply
power to other AV components. The type and num-
ber of outlets depends on the country in which you
purchased your AV receiver.
See pages 17–34 for hookup information.
