Connecting Your Components —Continued
•With connection , you can listen to and record audio from the CD player and listen in Zone 2.
•To connect the CD player digitally, use connection or . (For Zone 2, use and , or and .)
Connecting a CD Player
Connection AV receiver Signal flow CD player
CD IN L/R
⇐
Analog audio L/R output
DIGITAL COAXIAL IN 2
⇐
Digital coaxial output
DIGITAL OPTICAL IN 3
⇐
Digital optical output
COAXIAL
IN 2
COAXIAL
OUT
AUDIO
OUT
LR
OPTICAL
OUT
OPTICAL
IN 3
L
R
IN
CD
b
c
a
Step 1:
Choose a connection that matches your CD player ( , , or ), and then make the connection.
a b c
CD player
Connect one
or the other
a
b
c
a
b
a c
a
b
c
