Speaker Configuration
With these settings, you can specify which speakers are
connected and a crossover frequency for each speaker.
Specify “Full Band” for speakers that can output low fre-
quency bass sounds adequately, for example, speakers
with a good sized woofer. For smaller speakers, specify a
crossover frequency. Sounds below the crossover fre-
quency will be output by the subwoofer instead of the
speaker. Refer to your speaker’s manuals to determine the
optimum crossover frequencies. If you set up your speak-
ers using Audyssey MultEQ Room Correction and
Speaker Setup, please make sure manually that any THX
speakers are set to “80Hz(THX)” crossover.
■ Subwoofer
 Ye s
:
Select if a subwoofer is connected.
 No:
Select if no subwoofer is connected.
■ Front
 Full Band
 40Hz, 45Hz, 50Hz, 55Hz, 60Hz, 70Hz, 80Hz(THX)
to 130Hz, 150Hz, 200Hz
Note
•If the “Subwoofer” setting is set to “No”, the “Front” setting is
fixed at “Full Band”.
■ Center
*1
, Surround
*1
, Surr Back
*2*3*4*5
 Full Band
 40Hz, 45Hz, 50Hz, 55Hz, 60Hz, 70Hz, 80Hz(THX)
to 130Hz, 150Hz, 200Hz
 None:
Select if no speaker is connected.
■ Front Wide
*1*2*4*6
, Front High
*1*2*4*5
 Full Band
 40Hz, 45Hz, 50Hz, 55Hz, 60Hz, 70Hz, 80Hz(THX)
to 130Hz, 150Hz, 200Hz
 None
:
Select if no speaker is connected.
Note
*1
“Full Band” can be selected only when “Full Band” is
selected in the “Front” setting.
*2
If the “Surround” setting is set to “None”, this setting cannot
be selected.
*3
If the “Surround” setting is set to anything other than “Full
Band”, “Full Band” cannot be selected here.
*4
If the “Speakers Type(Front)” setting is set to “Bi-Amp”
(➔ 50), this setting cannot be selected.
*5
If the Powered Zone 2 is being used (➔ 77), this setting can-
not be selected.
*6
If the “Powered Zone 2” setting is set to “Act” (➔ 77), this
setting cannot be selected.
■ Surr Back Ch
 1ch:
Select if only one surround back speaker is con-
nected.
 2ch
:
Select if two (left and right) surround back speakers
are connected.
Note
• If the “Surr Back” setting is set to “None” (➔ 51), this setting
cannot be selected.
■ LPF of LFE
(Low-Pass Filter for the LFE Channel)
 80Hz, 90Hz, 100Hz, 110Hz, 120Hz
With this setting, you can specify the cutoff frequency
of the LFE channel’s low-pass filter (LPF), which can
be used to filter out unwanted hum. The LPF only
applies to sources that use the LFE channel.
■ Double Bass
With the Double Bass function, you can boost bass out-
put by feeding bass sounds from the front left, right, and
center channels to the subwoofer.
 On:
Double Bass function on.
 Off(THX):
Double Bass function off.
Note
• This function can be set only if the “Subwoofer” setting is set to
“Ye s”, and the “Front” setting is set to “Full Band”.
• If you’re using THX-certified speakers, select “Off(THX)”.
This setting is set automatically by Audyssey MultEQ
®
Room Correction and Speaker Setup function (➔ 28).
This setting is NOT set automatically by
Audyssey MultEQ Room Correction and Speaker Setup
function (➔ 28).
