NOTE: THE COMPONENTS IDENTIFIED BY MARK !
ARE CRITICAL FOR RISK OF FIRE AND
ELECTRIC SHOCK. REPLACE ONLY WITH
PART NUMBER SPECIFIED.
Note:
<D>: 120V model only
<A>: Australian model only
CAUTION: Replacement for transistor of mark *, if necessary
must be made from the same beta group (H
FE) as
the original type.
F/C ch.speaker terminal PC board (NAETC-7694-1R/1T)
CIRCUIT NO. PART NO. DESCRIPTION
Diodes
D6600 223163, 1SS133,
D6600 or 223205 or 1SS270A or
D6600 or 223222 WG713A
Coils
L6800~L6802 231176S
S-1.3C
<A>
Capacitors
C6830~C6832 374731034 0.01uF+/-5%,100V,Plastic
C6840~C6842 374731024
1000pF+/-5%,100V,Plastic
<A>
Resistors
R6830~R6832 453630824 8.2ohm+/-5%, 1W, Metal
Relays
RL6600,RL6602 25065563, NRL-2P5A-DC24-129,
25065517 or NRL-2P5A-DC24-098 or
25065586 NRL-2P5A-DC24-142
Terminal
P6800 25060337 NTM-6PDMN268 <D>
25060338
NTM-6PDMN269 <A>
Plugs
P6007A 25055167 NPLG-4P151
P6810D 25055166 NPLG-3P150
P6830 25055734 NPLG-3P690
Surround ch.speaker terminal PC board (NAETC-7695-1R/1T)
CIRCUIT NO. PART NO. DESCRIPTION
Diodes
D6603,D6605 223163, 1SS133,
D6603,D6605 223205 or 1SS270A or
D6603,D6605 223222 WG713A
Coils
L6803~L6806 231176S
S-1.3C
<A>
Capacitors
C6833~C6836 374731034 0.01uF+/-5%,100V,Plastic
C6843~C6846 374731024
1000pF+/-5%,100V,Plastic
<A>
Resistors
R6833~R6836 453630824 8.2ohm+/-5%, 1W, Metal
Relays
RL6603,RL6605 25065563, NRL-2P5A-DC24-129,
25065517 or NRL-2P5A-DC24-098 or
25065586 NRL-2P5A-DC24-142
Terminal
P6802 25060339 NTM-8PDMN270 <D>
P6802 25060340
NTM-8PDMN271
<A>
Plugs
P6008A 25055169 NPLG-6P153
P6812E 25055168 NPLG-5P152
P6832 25055734 NPLG-3P690
Fan driver circuit PC board (NAETC-7696-1R/1T)
CIRCUIT NO. PART NO. DESCRIPTION
Transistors
Q5601 2212445 2SK365-GR
Q5602,Q5603 2215864, KTC3199-GR,
Q5607,Q6701 2212115, 2SC2458-GR,
Q6702 2213284 or 2SC1740S-R or
2213285 2SC1740S-S
Q5604,Q5605 2215820, KRC104M,
Q5608,Q5609 221282 or DTC144ES or
2213560 RN1204
CIRCUIT NO. PART NO. DESCRIPTION
Transistors
Q5606 2203595, KTC2026-GR,
2202705, 2SD2394-E,
2202706 or 2SD2394-F or
2203594 KTC2026-Y
Q6704 2215995, KTA1267-GR,
2212125, 2SA1048-GR,
2213354 or 2SA933S-R or
2213355 2SA933S-S
Diodes
D5601 223163, 1SS133,
D5604~D5607 223205 or 1SS270A or
D5609,D5610 223222 WG713A
D5602,D5603 22380260, RL1N4003,
22380032 or 1SR139-100 or
22380035 GP104003E
D5611 224471303 MTZJ13C
D6701,D6702 223163, 1SS133,
223205 or 1SS270A or
223222 WG713A
D6703,D6704 224470512 MTZJ5.1B
Capacitors
C5602~C5604 394661017 100uF,35V, Elect.
C6701 394621017 100uF,6.3V, Elect.
C6704 394680107 1uF,50V, Elect.
C6706 394621017 100uF,6.3V, Elect.
Resistors
R5612 415471014 100ohm+/-5%,1/4W,NF carbon
R5613 453530474 4.7ohm+/-5%, 1/2W, Metal
R5616 441721224F 1.2kohm+/-5%, 2W, Metal oxide
Sockets
P6931A 25051230 NSCT-5P1020
P7701B 25052201, NSCT-5P2098,
25051271, NSCT-5P1060,
25051812 or NSCT-5P1599 or
25052014 NSCT-5P1801
JL6933A 25051088 NSCT-4P875
JL9503A 25051110 NSCT-6P897
Thermal detector PC board (NAETC-7697-1R/1T)
CIRCUIT NO. PART NO. DESCRIPTION
Thermistors
R5651 4000153 PTH9M04BF222TS2F333
R5653 4000150 PTH9M04BC222TS2F333 <D>
R5653 4000151
PTH9M04BD222TS2F333
<A>
Socket
JL6933B 25051088 NSCT-4P875
AC inlet PC board (NAETC-7700-1R/1T)
CIRCUIT NO. PART NO. DESCRIPTION
AC inlet
P901B 25055960 ! NPLG-2P913
Power amplifier PC board (NAAF-7706-1M/1N)
CIRCUIT NO. PART NO. DESCRIPTION
Transistors
Q6000~Q6006 2213284 or 2SC1740S-R or
Q6010~Q6016 2213285 2SC1740S-S
Q6020~Q6022 2215995, KTA1267-GR,
2212125, 2SA1048-GR,
2213354 or 2SA933S-R or
2213355 2SA933S-S
Q6023~Q6026 2211455 or 2SA1015-GR or
2211454 2SA1015-Y
Q6030~Q6032 2211634 or 2SC2229-Y or
2211633 2SC2229-O
DTR-7.3
PRINTED CIRCUIT BOARD-PART LIST 3
