Integra DTR-7.3 Service Manual

NOTE: THE COMPONENTS IDENTIFIED BY MARK !
ARE CRITICAL FOR RISK OF FIRE AND
ELECTRIC SHOCK. REPLACE ONLY WITH
PART NUMBER SPECIFIED.
Note: <D>: 120V model only <A>: Australian model only
CAUTION: Replacement for transistor of mark *, if necessary
must be made from the same beta group (H
FE) as
the original type.
CIRCUIT NO. PART NO. DESCRIPTION
Transistors
Q6033~Q6036 2203434 or KTD2061-Y or
2203010 2SC5171
Q6040~Q6042 2211354 or 2SA949-Y or
2211353 2SA949-O
Q6043~Q6046 2203424 or KTB1369-Y or
2203000 2SA1930
Q6050~Q6056 2202823 or * 2SC5200-O or
2202822 * 2SC5200-R
Q6060~Q6066 2202813 or * 2SA1943-O or
2202812 * 2SA1943-R
Q6070~Q6076 2214984 or 2SC2631-R or
2214985 2SC2631-S
Q6090~Q6092 2203424 or KTB1369-Y or
2203000 2SA1930
Q6100~Q6102 2203434 or KTD2061-Y or
2203010 2SC5171
Q6703 2215885, KTA1268-GR,
2211792, 2SA992-F,
2211793 or 2SA992-E or
2215886 KTA1268-BL
Diodes
D6000~D6006 223163, 1SS133,
223205 or 1SS270A or
223222 WG713A
Cores
L6000-L6002 5597-45502
L6010~L6012 5597-45502
Capacitors
C6000~C6006 374721024 1000pF+/-5%,50V,Plastic
C6020~C6022 394500477 4.7uF,160V, Elect.
C6023~C6026 394684707 47uF,50V, Elect.
C6030~C6036 374734734 0.047uF+/-5%,100V,Plastic
C6510~C6514 394690477 4.7uF,100V, Elect.
C6520~C6523 394690477 4.7uF,100V, Elect.
C6531,C6532 374721034 0.01uF+/-5%,50V,Plastic
C6901,C6902 3504373 15000uF,71V, Elect.
C6901,C6902 3504374 15000uF,71V, Elect.
C6901,C6902 3504373 15000uF,71V, Elect.
C6901,C6902 3504374 15000uF,71V, Elect.
Resistors
R6040~R6046 5210258 N06HR1KBC,Trimming
R6070~R6072 415476804 68ohm+/-5%,1/4W,NF carbon
R6073~R6076 415471814 180ohm+/-5%,1/4W,NF carbon
R6080~R6082 443521004 10ohm+/-5%, 1/2W, Metal oxide
R6083~R6086 415470224 2.2ohm+/-5%,1/4W,NF carbon
R6090~R6092 443521004 10ohm+/-5%, 1/2W, Metal oxide
R6093~R6096 415470224 2.2ohm+/-5%,1/4W,NF carbon
R6100~R6106 4000201, RF-5EGKR22,
4000132 or RGC55 0.22 or
4500245 BPR55FK0.22
R6130~R6136 453630824 8.2ohm+/-5%, 1W, Metal
R6230~R6232 415471214 120ohm+/-5%,1/4W,NF carbon
R6240~R6242 415471214 120ohm+/-5%,1/4W,NF carbon
R6250~R6252 415471804 18ohm+/-5%,1/4W,NF carbon
R6260~R6262 415471804 18ohm+/-5%,1/4W,NF carbon
R6270~R6272 415470224 2.2ohm+/-5%,1/4W,NF carbon
R6280~R6282 415470224 2.2ohm+/-5%,1/4W,NF carbon
R6510~R6514 453532294 0.22ohm+/-5%, 1/2W, Metal
R6520~R6523 453532294 0.22ohm+/-5%, 1/2W, Metal
Terminals
P5100A,P5101A 25060301 NTM-1P232(M1700)
P5201A,P5202A 25060301 NTM-1P232(M1700)
CIRCUIT NO. PART NO. DESCRIPTION
Sockets
P5003 2009990666UL NSAS-12P0929
P5004 2009990745UL NSAS-16P1040
P6007 2009990759UL NSAS-6P1070
P6008 2009990760UL NSAS-8P1071
P6810 2009990668UL NSAS-6P0931
P6812 2009990669UL NSAS-6P0932
P6952 2009990671UL NSAS-6P0934
Plugs
P6000~P6006 25056009 NPLG-4P0959
P6010,P6013 25056011 NPLG-6P0961
P6011,P6012 25056009 NPLG-4P0959
P6014~P6016 25056009 NPLG-4P0959
P6080~P6086 25055038 NPLG-2P29
P6931 25055701 NPLG-5P657
Bar
P6201 27141850 BBL50
Holder
P6214 27190608-1 UA-0 V0
Clamps
P6211~P6213 260226 CP-2S
P6216 260226 CP-2S
P6301~P6303 260224 CP-1S
P6305~P6307 260224 CP-1S
Heat sinks
Q6090A~Q6092
A
27160486 RAD-155
Screws
Q6090B~Q6092
B
838430107 3TTB+10S(BC),Self-tapping
Q6100B~Q6102
B
838430107 3TTB+10S(BC),Self-tapping
Surround ch. driver circuit PC board (NAAF-7707-1M/1N)
CIRCUIT NO. PART NO. DESCRIPTION
Transistors
Q5003~Q5006 2215896, * KTC3200-BL,
Q5013~Q5016 2210755, * 2SC1775A-E,
2210756 or * 2SC1775A-F or
2211733 * 2SC1845-E
Q5023~Q5026 2215896, KTC3200-BL,
2210755, 2SC1775A-E,
2210756 or 2SC1775A-F or
2211733 2SC1845-E
Q5033~Q5036 2215844, KTA1024-Y,
Q5043~Q5046 2211353, 2SA949-O,
Q5053~Q5056 2211354 or 2SA949-Y or
2215843 KTA1024-O
Q5083~Q5086 2215854, KTC3206-Y,
2211633, 2SC2229-O,
2211634 or 2SC2229-Y or
2215853 KTC3206-O
Diodes
D5003~D5006 224470562 MTZJ5.6B
Capacitors
C5003~C5006 393381007 10uF,50V, Elect.
C5013~C5016 374722215 220pF+/-10%,50V,Plastic
C5043~C5046 393341017 100uF,16V, Elect.
C5053~C5056 394681007 10uF,50V, Elect.
C5073~C5076 394691007 10uF,100V, Elect.
C5083~C5086 394672207 22uF,63V, Elect.
C5093~C5096 394684707 47uF,50V, Elect.
C5103~C5106 374721015 100pF+/-10%,50V,Plastic
C5123~C5126 394694707 47uF,100V, Elect.
C5133~C5136 394694707 47uF,100V, Elect.
DTR-7.3
PRINTED CIRCUIT BOARD-PART LIST 4
