Integra DTR-7.4 Service Manual

CIRCUIT NO. PART NO. DESCRIPTION
Resistors
R7245 435031034R1 RN72K1J-103JE,Carbon
R7247,R7248 435031034R1 RN72K1J-103JE,Carbon
R7249,R7250 435034724R1 RN72K1J-472JE,Carbon
R7251~R7256 435031034R1 RN72K1J-103JE,Carbon
R7258~R7260 435031034R1 RN72K1J-103JE,Carbon
R7265~R7268 435031034R1 RN72K1J-103JE,Carbon
R7271,R7282 435031034R1 RN72K1J-103JE,Carbon
R7272 435032214R1 RN72K1J-221JE,Carbon
R7275 435034724R1 RN72K1J-472JE,Carbon
R7277 435030004R1 RN72K1J-000JE,Carbon
R7279,R7280 435031024R1 RN72K1J-102JE,Carbon
R7284,R7286 435031034R1 RN72K1J-103JE,Carbon
R7289 435030004R1 RN72K1J-000JE,Carbon <D
>
R7289 435031034R1 RN72K1J-103JE,Carbon <A
>
R7290 435033334R1 RN72K1J-333JE,Carbon <A
>
R7293~R7295 435034724R1 RN72K1J-472JE,Carbon
R7297 435034724R1 RN72K1J-472JE,Carbon
R7301 435032244R1 RN72K1J-224JE,Carbon
R7309,R7329 435031034R1 RN72K1J-103JE,Carbon
R7315,R7316 435031024R1 RN72K1J-102JE,Carbon
R7330 435034724R1 RN72K1J-472JE,Carbon
R7338~R7340 435031034R1 RN72K1J-103JE,Carbon
R7371,R7376 435031034R1 RN72K1J-103JE,Carbon
R7379,R7380 435031034R1 RN72K1J-103JE,Carbon
R7382 435031024R1 RN72K1J-102JE,Carbon
R7386 435031034R1 RN72K1J-103JE,Carbon
R7389 435033334R1 RN72K1J-333JE,Carbon <A
>
R7390 435031034R1 RN72K1J-103JE,Carbon <D
>
R7390 435035634R1 RN72K1J-563JE,Carbon
R7391,R7392 435031034R1 RN72K1J-103JE,Carbon
R7393~R7395 435032724R1 RN72K1J-272JE,Carbon
R7397 435032724R1 RN72K1J-272JE,Carbon
R7431 435032214R1 RN72K1J-221JE,Carbon
R7432,R7547 435032224R1 RN72K1J-222JE,Carbon
R7490~R7497 435034714R1 RN72K1J-471JE,Carbon
R7501,R7502 435032214R1 RN72K1J-221JE,Carbon
R7504 435032734R1 RN72K1J-273JE,Carbon
R7505~R7509 435033314R1 RN72K1J-331JE,Carbon
R7511~R7526 435031034R1 RN72K1J-103JE,Carbon
R7538 435031814R1 RN72K1J-181JE,Carbon
R7539 435031514R1 RN72K1J-151JE,Carbon
R7541,R7542 435033314R1 RN72K1J-331JE,Carbon
R7543,R7552 435034714R1 RN72K1J-471JE,Carbon
R7544,R7553 435035614R1 RN72K1J-561JE,Carbon
R7545,R7554 435038214R1 RN72K1J-821JE,Carbon
R7546,R7555 435031224R1 RN72K1J-122JE,Carbon
R7548,R7557 435033924R1 RN72K1J-392JE,Carbon
R7551,R7558 435031234R1 RN72K1J-123JE,Carbon
R7556,R7566 435032224R1 RN72K1J-222JE,Carbon
R7562,R7564 435038214R1 RN72K1J-821JE,Carbon
R7563,R7572 435035614R1 RN72K1J-561JE,Carbon
R7565,R7575 435031224R1 RN72K1J-122JE,Carbon
R7567,R7577 435033924R1 RN72K1J-392JE,Carbon
R7571 435034714R1 RN72K1J-471JE,Carbon
R7573 435038214R1 RN72K1J-821JE,Carbon
R7574 435033314R1 RN72K1J-331JE,Carbon
R7576 435032224R1 RN72K1J-222JE,Carbon
R7578 435031234R1 RN72K1J-123JE,Carbon
R7581,R7583 435030004R1 RN72K1J-000JE,Carbon
R7585,R7587 435030004R1 RN72K1J-000JE,Carbon
Switches
S7542 25035714 or NPS-111-S677 o
r
S7556~S7559 25035718 NPS-111-S681
S7563~S7568 25035714 or NPS-111-S677 o
r
S7571~S7579 25035718 NPS-111-S681
S7581~S7591 25035714 or NPS-111-S677 o
r
25035718 NPS-111-S681
