Specifications
Intel® Centrino® Ultimate-N 6300
Intel® Centrino® Advanced-N + WiMAX 6250
Intel® Centrino® Advanced-N 6200
Intel® WiMAX/WiFi Link 5350
Intel® WiMAX/WiFi Link 5150
Intel® WiFi Link 5300
Intel® WiFi Link 5100
Intel® Centrino® Wireless-N 1000
Intel® Wireless WiFi Link 4965AGN
Intel® Wireless WiFi Link 4965AG_
Intel® PRO/Wireless 3945ABG Network Connection
Intel® PRO/Wireless 3945BG Network Connection
Intel® Centrino® Advanced-N 6200 and Intel® Centrino® Ultimate-N
6300
Form Factor PCI Express* Full-Mini Card and Half-Mini Card
Dimensions Full-Mini Card: Width 2.00 in x Length 1.18 in x Height 0.18 in
(50.95 mm x 30 mm x 4.5 mm)
Half-Mini Card: Width 1.049 in x Length 1.18 in x Height 0.18 in
(26.64 mm x 30 mm x 4.5 mm)
Antenna
Interface
Connector
Hirose U.FL-R-SMT mates with cable connector U.FL-LP-066
Antenna
Diversity
On-board diversity
Connector
Interface
52-pin Mini Card edge connector
Voltage 3.3 V
Operating
Temperature
0 to +80 degrees Celsius
Humidity 50% to 95% non-condensing (at temperatures of 25 ºC to 35 ºC)
Frequency
Modulation
5 GHz (802.11a/n) 2.4 GHz (802.11b/g/n)
Frequency
band
5.15 GHz - 5.85 GHz (dependent
on country)
2.400 - 2.4835 GHz (dependent
on country)
Modulation BPSK, QPSK, 16 QAM, 64 QAM CCK, DQPSK, DBPSK
Wireless
Medium
5 GHz UNII: Orthogonal
Frequency Division Multiplexing
(OFDM)
2.4 GHz ISM: Orthogonal
Frequency Division Multiplexing
(OFDM)
Channels 4 to 12 (dependent on country) Channel 1-11 (US only)
Channel 1-13 (Japan, Europe)
IEEE
802.11n
Data Rates
Intel® Centrino® Ultimate-N 6300
Tx/Rx: 450, 405, 360, 300, 270, 243, 240, 216.7, 195, 180, 173.3,
150, 144, 135, 130, 120, 117, 115.5, 90, 86.667, 72.2, 65, 60,
57.8, 45, 43.3, 30, 28.9, 21.7, 15, 14.4, 7.2 Mbps
Intel® PROSet/Wireless WiFi Connection Utility User's Guide
