WiMAX
Frequency
band
2.5-2.7 GHz (3A Profile)
Modulation UL - QPSK, 16 QAM
DL - QPSK, 16 QAM, 64 QAM
Wireless
Medium
Duplex mode: TDD operations Scalable OFDMA (SOFDMA): 512
and 1024 FFT
sub-carrier permutation: PUSC Channel bandwidths: 5 MHz and
10 MHz
WiMAX
Network
Release
Feature set
SPWG/NWG Release 1.0
SPWG/NWG Release 1.5
Rate
Performance
10 Mbps DL and 4 Mbps UL @ peak rate
(OTA performance, 10MHz channel)
RF
Transmitter
Output
Power
Compliance with Power class 2
WiMAX
General
Operating
Systems
Microsoft Windows* XP (32-bit and 64-bit)
Windows Vista* (32-bit and 64-bit)
Windows* 7 (32-bit and 64-bit)
Standard
Compliance
802.16e-2005 Corrigenda 2 (D4)
WiMAX
System
Profile
Feature set
Mobile WiMAX release 1, Wave II
Profile 3A
Security Key Management Protocol (PKMv2)
Encryption 128-bit CCMP (Counter-Mode/CBC-MAC) based on AES encryption
Intel® WiFi Link 5100 and Intel® WiFi Link 5300
Form Factor PCI Express* Full-Mini Card and Half-Mini Card
Dimensions Full-Mini Card: Width 2.00 in x Length 1.18 in x Height 0.18 in
(50.95 mm x 30 mm x 4.5 mm)
Half-Mini Card: Width 1.049 in x Length 1.18 in x Height 0.18 in
(26.64 mm x 30 mm x 4.5 mm)
Antenna
Interface
Connector
Hirose U.FL-R-SMT mates with cable connector U.FL-LP-066
Antenna
Diversity
On-board diversity
Connector
Interface
52-pin Mini Card edge connector
