Intel® Centrino® Wireless-N 1000
WiFi /
WiMAX
Form Factor PCI Express* Mini Card and Half-Mini Card
SKUs Intel® Centrino® Wireless-N 1000 - 1X2 MC/HMC
Dimensions Mini Card: Width 2.0 in x Length 1.18 in x Height 0.18 in (50.80
mm x 30 mm x 4.5 mm)
Half-Mini Card: Width 1.049 in x Length 1.18 in x Height 0.18 in
(26.64 mm x 30 mm x 4.5 mm)
Antenna
Interface
Connector
Hirose U.FL-R-SMT mates with cable connector U.FL-LP-066
Antenna
Diversity
On-board diversity
Connector
Interface
52-pin Mini Card edge connector
Voltage 3.3 V
Operating
Temperature
0 to +80 degrees Celsius
Humidity 50% to 90% non-condensing (at temperatures of 25 ºC to 35 ºC)
WiFi
Frequency
Modulation
2.4 GHz (802.11b/g/n)
Frequency
band
2.41-2.474 GHz (dependent on country)
Modulation BPSK, QPSK, 16 QAM, 64 QAM, CCK, DQPSK, DBPSK
Wireless
Medium
2.4 GHz ISM: Orthogonal Frequency Division Multiplexing (OFDM)
Channels Channel 1-11 (US)
Channel 1-13 (Japan, Europe)
Channels 4 to 12 (Other countries, dependent on country)
IEEE
802.11n
Data Rates
300, 270, 243, 240, 180, 150, 144, 135, 130, 120, 117, 115.5, 90,
86.667, 72.2, 65, 60, 57.8, 45, 43.3, 30, 28.9, 21.7, 15, 14.4, 7.2
Mbps
IEEE
802.11g
Data Rates
54, 48, 36, 24, 18, 12, 9, 6 Mbps
IEEE
802.11b
Data Rates
11, 5.5, 2, 1 Mbps
WiFi
General
Operating
Systems
Microsoft Windows* XP (32 and 64 bit) and Windows Vista* (32 and
64 bit)
Wi-Fi
Alliance*
certification
Wi-Fi* certification for 802.11b, 802.11g, 802.11h, 802.11d, WPA-
Personal, WPA-Enterprise, WPA2-Personal, WPA2-Enterprise, WMM,
WMM Power Save, EAP-SIM, LEAP, PEAP, TKIP, EAP-FAST, EAP-TLS,
Intel® PROSet/Wireless WiFi Connection Utility User's Guide
