Intel BLKD101GGCL - Board Components Shown in Figure 2

Product Description
13
Table 2. Board Components Shown in Figure 2
Item/callout
from Figure 2 Description
A
Front panel audio connector
B
Audio codec
C
PCI Express x16 add-in card connector
D
Ethernet device
E
Back panel connectors
F
+12V power connector (ATX12V)
G
Rear chassis fan connector
H
LGA775 processor socket
I
ATI Radeon Xpress 200 Northbridge
J
DIMM Channel A sockets [2]
K
Processor fan connector
L
Chassis intrusion connector
M
Legacy I/O controller
N
Main power connector
O
Diskette drive connector
P
Parallel ATE IDE connectors [2]
Q
Battery
R
Front chassis fan connector
S
Serial ATA connectors [4]
T
Auxiliary front panel power LED connector
U
Front panel connector
V
4 Mbit Firmware Hub (FWH)
W
IXP 450 Southbridge
X
Speaker
Y
Front panel USB connector
Z
BIOS Setup configuration jumper block
AA
PCI Conventional bus add-in card connectors [2]
BB
Front panel USB connector
CC
PCI Express x1 bus add-in card connector
DD
Standby power indicator LED
