2 Technical Reference
What This Chapter Contains
2.1 Memory Map ................................................................................................................31
2.2 DMA Channels.............................................................................................................32
2.3 Fixed I/O Map...............................................................................................................33
2.4 Interrupts......................................................................................................................34
2.5 PCI Configuration Space Map......................................................................................35
2.6 PCI Conventional Interrupt Routing Map .....................................................................35
2.7 Connectors...................................................................................................................36
2.8 Jumper Block ...............................................................................................................45
2.9 Mechanical Considerations..........................................................................................46
2.10 Electrical Considerations..............................................................................................48
2.11 Thermal Considerations...............................................................................................50
2.12 Reliability......................................................................................................................52
2.13 Environmental ..............................................................................................................53
2.14 Regulatory Compliance................................................................................................54
2.1 Memory Map
Table 9 lists the system memory map.
Table 9. System Memory Map
Address Range (decimal) Address Range (hex) Size Description
1024 K - 4194304 K 100000 - FFFFFFFF 4095 MB Extended memory
960 K - 1024 K F0000 - FFFFF 64 KB Runtime BIOS
896 K - 960 K E8000 - EFFFF 32 KB Reserved
800 K - 896 K C8000 – E7FFF 128 KB Potential available high DOS
memory (open to the PCI
Conventional bus). Dependent on
video adapter used.
640 K - 800 K A0000 - C7FFF 160 KB Video memory and BIOS
639 K - 640 K 9FC00 - 9FFFF 1 KB Extended BIOS data (movable by
memory manager software)
512 K - 639 K 80000 - 9FBFF 127 KB Extended conventional memory
0 K - 512 K 00000 - 7FFFF 512 KB Conventional memory
