Intel BLKD101GGCL - Component-Side Connectors Shown in Figure 7; Front Panel Audio Connector

Technical Reference
39
Table 16. Component-side Connectors Shown in Figure 7
Item/callout
from Figure 7 Description
A
PCI Conventional bus add-in card connector 2
B
PCI Conventional bus add-in card connector 1
C
Front panel audio connector
D
PCI Express x1 bus add-in card connector
E
PCI Express x16 add-in card connector
F
Rear chassis fan connector
G
+12V power connector (ATX12V)
H
Processor fan connector
I
Chassis intrusion connector
J
Main power connector
K
Diskette drive connector
L
Primary parallel ATA IDE connector
M
Secondary parallel ATA IDE connector
N
Serial ATA connector 1
O
Front chassis fan connector
P
Serial ATA connector 2
Q
Serial ATA connector 4
R
Serial ATA connector 3
S
Auxiliary front panel power LED connector
T
Front panel connector
U
Front panel USB connector
V
Front panel USB connector
Table 17. Front Panel Audio Connector
Pin Signal Name Pin Signal Name
1 Port F Left Channel 2 Ground
3 Port F Right Channel 4 Presence# (dongle present)
5 Port E Right Channel 6 Port F Sense return
(jack detection)
7 Port E and Port F
Sense send (jack detection)
8 Key
9 Port E Left Channel 10 Port E Sense return
(jack detection)
#
INTEGRATOR’S NOTE
The front panel audio connector is colored yellow.
