Intel BLKD101GGCL - Chassis Intrusion Connector; Serial ATA Connectors; Processor Fan Connector; Chassis Fan Connectors

Intel Desktop Board D101GGC Technical Product Specification
40
Table 18. Chassis Intrusion Connector
Pin Signal Name
1 Intruder
2 Ground
Table 19. Serial ATA Connectors
Pin Signal Name
1 Ground
2 TXP
3 TXN
4 Ground
5 RXN
6 RXP
7 Ground
Table 20. Processor Fan Connector
Pin Signal Name
1 Ground
2 +12 V
3 FAN_TACH
4 FAN_CONTROL
Table 21. Chassis Fan Connectors
Pin Signal Name
1 Control
2 +12 V
3 Tach
