2.3 Fixed I/O Map
Table 11. I/O Map
Address (hex) Size Description
0000 - 00FF 256 bytes Used by the Desktop Board D101GGC. Refer to the
IXP 450 data sheet for dynamic addressing information.
0170 - 0177 8 bytes Secondary Parallel ATA IDE channel command block
01F0 - 01F7 8 bytes Primary Parallel ATA IDE channel command block
0228 - 022F
(Note 1)
8 bytes LPT3
0278 - 027F
(Note 1)
8 bytes LPT2
02E8 - 02EF
(Note 1)
8 bytes COM4
02F8 - 02FF
(Note 1)
8 bytes COM2
0374 - 0377 4 bytes Secondary Parallel ATA IDE channel control block
0377, bits 6:0 7 bits Secondary IDE channel status port
0378 - 037F 8 bytes LPT1
03E8 - 03EF 8 bytes COM3
03F0 - 03F5 6 bytes Diskette channel
03F6 – 03F7 1 byte Primary Parallel ATA IDE channel control block
03F8 - 03FF 8 bytes COM1
04D0 - 04D1 2 bytes Edge/level triggered PIC
LPTn + 400 8 bytes ECP port, LPTn base address + 400h
0CF8 - 0CFB
(Note 2)
4 bytes PCI Conventional bus configuration address register
0CF9
(Note 3)
1 byte Reset control register
0CFC - 0CFF 4 bytes PCI Conventional bus configuration data register
FB00 – FB07 8 bytes Primary Parallel ATA IDE bus master registers
FB08 – FB0F 8 bytes Secondary Parallel ATA IDE bus master registers
Notes:
1. Default, but can be changed to another address range
2. Dword access only
3. Byte access only
NOTE
Some additional I/O addresses are not available due to IXP 450 address aliasing. The IXP 450
data sheet provides more information on address aliasing.
