Land Listing
38 Datasheet
DDR0_DQ[3] R42 CMOS I/O
DDR0_DQ[30] C38 CMOS I/O
DDR0_DQ[31] B38 CMOS I/O
DDR0_DQ[32] B5 CMOS I/O
DDR0_DQ[33] C4 CMOS I/O
DDR0_DQ[34] F1 CMOS I/O
DDR0_DQ[35] G3 CMOS I/O
DDR0_DQ[36] B6 CMOS I/O
DDR0_DQ[37] C6 CMOS I/O
DDR0_DQ[38] F3 CMOS I/O
DDR0_DQ[39] F2 CMOS I/O
DDR0_DQ[4] W40 CMOS I/O
DDR0_DQ[40] H2 CMOS I/O
DDR0_DQ[41] H1 CMOS I/O
DDR0_DQ[42] L1 CMOS I/O
DDR0_DQ[43] M1 CMOS I/O
DDR0_DQ[44] G1 CMOS I/O
DDR0_DQ[45] H3 CMOS I/O
DDR0_DQ[46] L3 CMOS I/O
DDR0_DQ[47] L2 CMOS I/O
DDR0_DQ[48] N1 CMOS I/O
DDR0_DQ[49] N2 CMOS I/O
DDR0_DQ[5] W42 CMOS I/O
DDR0_DQ[50] T1 CMOS I/O
DDR0_DQ[51] T2 CMOS I/O
DDR0_DQ[52] M3 CMOS I/O
DDR0_DQ[53] N3 CMOS I/O
DDR0_DQ[54] R4 CMOS I/O
DDR0_DQ[55] T3 CMOS I/O
DDR0_DQ[56] U4 CMOS I/O
DDR0_DQ[57] V1 CMOS I/O
DDR0_DQ[58] Y2 CMOS I/O
DDR0_DQ[59] Y3 CMOS I/O
DDR0_DQ[6] U41 CMOS I/O
DDR0_DQ[60] U1 CMOS I/O
DDR0_DQ[61] U3 CMOS I/O
DDR0_DQ[62] V4 CMOS I/O
DDR0_DQ[63] W4 CMOS I/O
DDR0_DQ[7] T42 CMOS I/O
Table 4-1. Land Listing by Land Name
(Sheet 3 of 36)
Land Name
Land
No.
Buffer
Type
Direction
DDR0_DQ[8] N41 CMOS I/O
DDR0_DQ[9] N43 CMOS I/O
DDR0_DQS_N[0] U43 CMOS I/O
DDR0_DQS_N[1] M41 CMOS I/O
DDR0_DQS_N[2] G41 CMOS I/O
DDR0_DQS_N[3] B40 CMOS I/O
DDR0_DQS_N[4] E4 CMOS I/O
DDR0_DQS_N[5] K3 CMOS I/O
DDR0_DQS_N[6] R3 CMOS I/O
DDR0_DQS_N[7] W1 CMOS I/O
DDR0_DQS_P[0] T43 CMOS I/O
DDR0_DQS_P[1] L41 CMOS I/O
DDR0_DQS_P[2] F41 CMOS I/O
DDR0_DQS_P[3] B39 CMOS I/O
DDR0_DQS_P[4] E3 CMOS I/O
DDR0_DQS_P[5] K2 CMOS I/O
DDR0_DQS_P[6] R2 CMOS I/O
DDR0_DQS_P[7] W2 CMOS I/O
DDR0_MA[0] A20 CMOS O
DDR0_MA[1] B21 CMOS O
DDR0_MA[10] B19 CMOS O
DDR0_MA[11] A26 CMOS O
DDR0_MA[12] B26 CMOS O
DDR0_MA[13] A10 CMOS O
DDR0_MA[14] A28 CMOS O
DDR0_MA[15] B29 CMOS O
DDR0_MA[2] C23 CMOS O
DDR0_MA[3] D24 CMOS O
DDR0_MA[4] B23 CMOS O
DDR0_MA[5] B24 CMOS O
DDR0_MA[6] C24 CMOS O
DDR0_MA[7] A25 CMOS O
DDR0_MA[8] B25 CMOS O
DDR0_MA[9] C26 CMOS O
DDR0_ODT[0] F12 CMOS O
DDR0_ODT[1] C9 CMOS O
DDR0_ODT[2] B11 CMOS O
DDR0_ODT[3] C7 CMOS O
DDR0_RAS# A15 CMOS O
Table 4-1. Land Listing by Land Name
(Sheet 4 of 36)
Land Name
Land
No.
Buffer
Type
Direction

Intel Core i7 Extreme Edition Specifications

General

Socket	LGA 1366
TDP	130W
Max Memory Size	24 GB
PCI Express Version	2.0
Virtualization Technology	Yes
Hyper-Threading Technology	Yes
Turbo Boost Technology	Yes
Memory Types	DDR3-1066
