Intel Core i7 Extreme Edition User Manual

Land Listing
Datasheet 39
DDR0_RESET# D32 CMOS O
DDR0_WE# B13 CMOS O
DDR1_BA[0] C18 CMOS O
DDR1_BA[1] K13 CMOS O
DDR1_BA[2] H27 CMOS O
DDR1_CAS# E14 CMOS O
DDR1_CKE[0] H28 CMOS O
DDR1_CKE[1] E27 CMOS O
DDR1_CKE[2] D27 CMOS O
DDR1_CKE[3] C27 CMOS O
DDR1_CLK_N[0] D21 CLOCK O
DDR1_CLK_N[1] G20 CLOCK O
DDR1_CLK_N[2] L18 CLOCK O
DDR1_CLK_N[3] H19 CLOCK O
DDR1_CLK_P[0] C21 CLOCK O
DDR1_CLK_P[1] G19 CLOCK O
DDR1_CLK_P[2] K18 CLOCK O
DDR1_CLK_P[3] H18 CLOCK O
DDR1_CS#[0] D12 CMOS O
DDR1_CS#[1] A8 CMOS O
DDR1_CS#[4] C17 CMOS O
DDR1_CS#[5] E10 CMOS O
DDR1_DQ[0] AA37 CMOS I/O
DDR1_DQ[1] AA36 CMOS I/O
DDR1_DQ[10] P39 CMOS I/O
DDR1_DQ[11] N39 CMOS I/O
DDR1_DQ[12] R34 CMOS I/O
DDR1_DQ[13] R35 CMOS I/O
DDR1_DQ[14] N37 CMOS I/O
DDR1_DQ[15] N38 CMOS I/O
DDR1_DQ[16] M35 CMOS I/O
DDR1_DQ[17] M34 CMOS I/O
DDR1_DQ[18] K35 CMOS I/O
DDR1_DQ[19] J35 CMOS I/O
DDR1_DQ[2] Y35 CMOS I/O
DDR1_DQ[20] N34 CMOS I/O
DDR1_DQ[21] M36 CMOS I/O
DDR1_DQ[22] J36 CMOS I/O
DDR1_DQ[23] H36 CMOS I/O
Table 4-1. Land Listing by Land Name
(Sheet 5 of 36)
Land Name
Land
No.
Buffer
Type
Direction
DDR1_DQ[24] H33 CMOS I/O
DDR1_DQ[25] L33 CMOS I/O
DDR1_DQ[26] K32 CMOS I/O
DDR1_DQ[27] J32 CMOS I/O
DDR1_DQ[28] J34 CMOS I/O
DDR1_DQ[29] H34 CMOS I/O
DDR1_DQ[3] Y34 CMOS I/O
DDR1_DQ[30] L32 CMOS I/O
DDR1_DQ[31] K30 CMOS I/O
DDR1_DQ[32] E9 CMOS I/O
DDR1_DQ[33] E8 CMOS I/O
DDR1_DQ[34] E5 CMOS I/O
DDR1_DQ[35] F5 CMOS I/O
DDR1_DQ[36] F10 CMOS I/O
DDR1_DQ[37] G8 CMOS I/O
DDR1_DQ[38] D6 CMOS I/O
DDR1_DQ[39] F6 CMOS I/O
DDR1_DQ[4] AA35 CMOS I/O
DDR1_DQ[40] H8 CMOS I/O
DDR1_DQ[41] J6 CMOS I/O
DDR1_DQ[42] G4 CMOS I/O
DDR1_DQ[43] H4 CMOS I/O
DDR1_DQ[44] G9 CMOS I/O
DDR1_DQ[45] H9 CMOS I/O
DDR1_DQ[46] G5 CMOS I/O
DDR1_DQ[47] J5 CMOS I/O
DDR1_DQ[48] K4 CMOS I/O
DDR1_DQ[49] K5 CMOS I/O
DDR1_DQ[5] AB36 CMOS I/O
DDR1_DQ[50] R5 CMOS I/O
DDR1_DQ[51] T5 CMOS I/O
DDR1_DQ[52] J4 CMOS I/O
DDR1_DQ[53] M6 CMOS I/O
DDR1_DQ[54] R8 CMOS I/O
DDR1_DQ[55] R7 CMOS I/O
DDR1_DQ[56] W6 CMOS I/O
DDR1_DQ[57] W7 CMOS I/O
DDR1_DQ[58] Y10 CMOS I/O
DDR1_DQ[59] W10 CMOS I/O
Table 4-1. Land Listing by Land Name
(Sheet 6 of 36)
Land Name
Land
No.
Buffer
Type
Direction

Intel Core i7 Extreme Edition Specifications

General

Socket	LGA 1366
TDP	130W
Max Memory Size	24 GB
PCI Express Version	2.0
Virtualization Technology	Yes
Hyper-Threading Technology	Yes
Turbo Boost Technology	Yes
Memory Types	DDR3-1066
