Land Listing
40 Datasheet
DDR1_DQ[6] Y40 CMOS I/O
DDR1_DQ[60] V9 CMOS I/O
DDR1_DQ[61] W5 CMOS I/O
DDR1_DQ[62] AA7 CMOS I/O
DDR1_DQ[63] W9 CMOS I/O
DDR1_DQ[7] Y39 CMOS I/O
DDR1_DQ[8] P34 CMOS I/O
DDR1_DQ[9] P35 CMOS I/O
DDR1_DQS_N[0] Y37 CMOS I/O
DDR1_DQS_N[1] R37 CMOS I/O
DDR1_DQS_N[2] L36 CMOS I/O
DDR1_DQS_N[3] L31 CMOS I/O
DDR1_DQS_N[4] D7 CMOS I/O
DDR1_DQS_N[5] G6 CMOS I/O
DDR1_DQS_N[6] L5 CMOS I/O
DDR1_DQS_N[7] Y9 CMOS I/O
DDR1_DQS_P[0] Y38 CMOS I/O
DDR1_DQS_P[1] R38 CMOS I/O
DDR1_DQS_P[2] L35 CMOS I/O
DDR1_DQS_P[3] L30 CMOS I/O
DDR1_DQS_P[4] E7 CMOS I/O
DDR1_DQS_P[5] H6 CMOS I/O
DDR1_DQS_P[6] L6 CMOS I/O
DDR1_DQS_P[7] Y8 CMOS I/O
DDR1_MA[0] J14 CMOS O
DDR1_MA[1] J16 CMOS O
DDR1_MA[10] H14 CMOS O
DDR1_MA[11] E23 CMOS O
DDR1_MA[12] E24 CMOS O
DDR1_MA[13] B14 CMOS O
DDR1_MA[14] H26 CMOS O
DDR1_MA[15] F26 CMOS O
DDR1_MA[2] J17 CMOS O
DDR1_MA[3] L28 CMOS O
DDR1_MA[4] K28 CMOS O
DDR1_MA[5] F22 CMOS O
DDR1_MA[6] J27 CMOS O
DDR1_MA[7] D22 CMOS O
DDR1_MA[8] E22 CMOS O
Table 4-1. Land Listing by Land Name
(Sheet 7 of 36)
Land Name
Land
No.
Buffer
Type
Direction
DDR1_MA[9] G24 CMOS O
DDR1_ODT[0] D11 CMOS O
DDR1_ODT[1] C8 CMOS O
DDR1_ODT[2] D14 CMOS O
DDR1_ODT[3] F11 CMOS O
DDR1_RAS# G14 CMOS O
DDR1_RESET# D29 CMOS O
DDR1_WE# G13 CMOS O
DDR2_BA[0] A17 CMOS O
DDR2_BA[1] F17 CMOS O
DDR2_BA[2] L26 CMOS O
DDR2_CAS# F16 CMOS O
DDR2_CKE[0] J26 CMOS O
DDR2_CKE[1] G26 CMOS O
DDR2_CKE[2] D26 CMOS O
DDR2_CKE[3] L27 CMOS O
DDR2_CLK_N[0] J21 CLOCK O
DDR2_CLK_N[1] K20 CLOCK O
DDR2_CLK_N[2] G21 CLOCK O
DDR2_CLK_N[3] L21 CLOCK O
DDR2_CLK_P[0] J22 CLOCK O
DDR2_CLK_P[1] L20 CLOCK O
DDR2_CLK_P[2] H21 CLOCK O
DDR2_CLK_P[3] L22 CLOCK O
DDR2_CS#[0] G16 CMOS O
DDR2_CS#[1] K14 CMOS O
DDR2_CS#[4] E17 CMOS O
DDR2_CS#[5] D9 CMOS O
DDR2_DQ[0] W34 CMOS I/O
DDR2_DQ[1] W35 CMOS I/O
DDR2_DQ[10] R39 CMOS I/O
DDR2_DQ[11] T36 CMOS I/O
DDR2_DQ[12] W39 CMOS I/O
DDR2_DQ[13] V39 CMOS I/O
DDR2_DQ[14] T41 CMOS I/O
DDR2_DQ[15] R40 CMOS I/O
DDR2_DQ[16] M39 CMOS I/O
DDR2_DQ[17] M40 CMOS I/O
DDR2_DQ[18] J40 CMOS I/O
Table 4-1. Land Listing by Land Name
(Sheet 8 of 36)
Land Name
Land
No.
Buffer
Type
Direction

Intel Core i7 Extreme Edition Specifications

General

Socket	LGA 1366
TDP	130W
Max Memory Size	24 GB
PCI Express Version	2.0
Virtualization Technology	Yes
Hyper-Threading Technology	Yes
Turbo Boost Technology	Yes
Memory Types	DDR3-1066
